16. Start Wizard
16.1 New drive start-up setting process
When a new drive is powered on, it directly enters the Start Wizard. There are three modes in
the start-up setting process: Start Wizard, Exit Wizard and Test Mode.
(1) Start Wizard:
 In Start Wizard, you can set drive’s parameters such as Calendar, Maximum operation
frequency and Maximum voltage…; refer to Table 1 for setting items and orders.
 The drive exits Start Wizard when you finish the complete setting process, and will not
enter this process when rebooting the power.
(2) Exit Wizard:
 Exit the Start Wizard mode. The drive does not go to Start Wizard when rebooting the
power.
(3) Test Mode:
 This function is hidden to avoid misuse. Refer to the following flow chart to enter Test
Mode.
 When the drive is in Test mode, it temporarily disables the Start Wizard and Exit Wizard
mode.
 The Test Mode is designed for distributors / suppliers / clients to manage and operate
the drive before shipping it out.
 If you enter Test Mode without exiting the Start Wizard process, the drive will begin with
the new drive start-up process upon next power on.
Setting
Order
Description
Parameter
1
Calendar
N/A
2
Output frequency of motor 1
01-01
3
Output voltage of motor 1
01-02
4
Full-load current for induction motor 1 (A)
05-01
5
Number of poles for induction motor 1
05-04
6
Rated speed for induction motor 1 (rpm)
05-03
7
Minimum output frequency of motor 1
01-07
8
Maximum operation frequency
01-00
9
Master frequency command source (AUTO) / Source
selection of the PID target
00-20
10
Operation command source (AUTO)
00-21
11
V/F curve selection
01-43
12
Acceleration time 1
01-12
13
Deceleration time 1
01-13
Table 1. Start Wizard setting items
