Chapter 12 Description of Parameter SettingsCP2000
12.1-02-3
50: Slave dEb action to execute
51: Selection for PLC mode bit0
52: Selection for PLC mode bit1
53: Trigger CANopen quick stop
54: UVW output electromagnetic valve switch
55: Brake release
56: Local / Remote Selection
58: Enable fire mode with RUN command
59: Enable fire mode without RUN command
60: Disable all the motors
61: Disable Motor 1
62: Disable Motor 2
63: Disable Motor 3
64: Disable Motor 4
65: Disable Motor 5
66: Disable Motor 6
67: Disable Motor 7
68: Disable Motor 8
69: Preheating command
This parameter selects the functions for each multi-function terminal.
Pr.02-26–Pr.02-31 are entity input terminals only when the extension cards are installed,
otherwise, there are virtual terminals. For example, when using the multi-function extension card
EMC-D42A, Pr. 02-26–Pr. 02-29 are defined as the corresponded parameters for MI10–MI13. In
this case, Pr. 02-30–Pr. 02-31 are virtual terminals.
When Pr.02-12 is defined as virtual terminal, use digital keypad KPC-CC01 or communication
method to change its status (0: ON; 1: OFF) of bit8–15.
If Pr.02-00 is set to three-wire operation control, terminal MI1 is for the STOP contact. The
function set previously for this terminal is automatically invalid.
Summary of function settings
Take the normally open contact (N.O.) for example, ON: contact is closed, OFF: contact is open
Settings Functions Descriptions
0
No Function
1
Multi-step speed
command 1
You can set 15 steps of speed or 15 positions with the digital status
of these 4 terminals. You can use 16-steps of speed if you include
the master speed when setting as 15 steps of speed. (Refer to
Parameter Group 04 Multi-step Speed Parameters.)
2
Multi-step speed
command 2
3
Multi-step speed
command 3
4
Multi-step speed
command 4
