DeltaLab DGFX1 - Wah and Stompbox Effects; Wah Effect; Stompbox Simulation

User’s Manual
Guitar Multi
-
Effects Pedal
19
The wah effect creates a unique tone by filtering frequencies via
the expression pedal.
Range: 0–100 (except for polarity, which will be displayed as Up
or Down).
Wah
1
2
Type
Name
AutoWah
SweepWah
PedalWah
LCD
Display
T.Wah
S.Wah
P.Wah
Description
AutoWah
SweepWah
PedalWah
PARA1
Sensitivity
Speed
Polarity
PARA2
Q
Q
/
PARA3
Grade
/
/
This unit contains models of 11 popular distortion stompboxes,
each of which can be tweaked just like the original model.
The distortion modules offer up to four parameters.
DRIVE controls the distortion level. LEVEL controls volume.
TONE determines the brightness of the tone.
Drive parameters can be adjusted from 1 thru 100.
Tone parameters can be adjusted from –50 thru +50.
Volume parameters can be adjusted from 1 thru 100.
Stomp
1
2
3
4
5
6
