User’s Manual
Guitar Multi
-
Effects Pedal
7
Power Supply
Patches
SettoPLAY
HowtoSelectaPatch
Set the EFFECT SELECTION
knob button to PLAY.
Use BANK– or BANK+ button
to select a bank number. The
LCD displays the current bank
number (0–7 and A–H) with
the relevant tone name and
effect chain.
Connect all cables.
Switch on the DGFX1.
After the power is on,
the LCD displays “DGFX1”
followed by any previously
saved patch and effects chain.
1
2
3
NOTE: The unit has up to 96 patches:
48 default settings (0–1 and 7–6), and
48 user patches (A–1 and H–6).
1
2
NOTE: The PLAY mode will be automatically selected after you turn the unit on, even if
the knob has been set to a position other than PLAY.
