Deltech HGEN Series - Air-Cooled Units: Electrical Schematics

9
SPECIFICATIONS: AIR-COOLED UNITS
General Arrangement Drawing:
Model HGEN800A
MODEL
DIMENSIONS, INCHES (MM)
INLET/OUTLET
CONNECTIONS
WEIGHT
Lb. (kg)
A B C D E F G H J K L
HGEN800A
31.10
(790)
21.10
(536)
10.00
(254)
26.77
(680)
28.35
(720)
37.40
(950)
41.34
(1050)
59.83
(1519.6)
35.22
(894.5)
6.12
(155.5)
3.35
(85)
3" ANSI Flange
695
(315)
WETTED AIR INLET
DRIED AIR OUTLET
COOLING AIR FLOW
REAR VIEW FRONT VIEWLEFT SIDE VIEW
TOP VIEW
G
F
E
D
G
JK
L
E
A
B
C
DRAIN OUTLET (2)
NPT3/8"
HOLE FOR MAIN POWER
4-Ø10 [0.394] HOLES
H
