PROBLEM: Bent Crown
SOLUTION: The wrong wire size is being used for the job being stitched. The
thickness adjustment setting could be incorrect or the Supporter is retracting too
easily. Check to make sure the correct wire size is being used (refer to page 3).
Check the work thickness adjustment setting (refer to page 6). Check the
tension of the Supporter Spring and increase the tension or replace the Spring.
PROBLEM: Left Leg Missing
SOLUTION: The wire is slipping in the Grip. Clean the Grip unless it is worn,
If worn, reverse the Grip within the Grip Holder or replace it (refer to page 7).
PROBLEM: Right Leg Missing
SOLUTION: The corner of the Swivel is too sharp. Check the Swivel. If the
corner over which the wire is formed is too sharp, stone the corner slightly.
PROBLEM: Staple Comes out in Pieces
SOLUTION: Either the Swivel is sticking or its corner is too sharp. Clean and
lubricate the Swivel (refer to page 6). Check the Swivel. If the
corner over which the wire is formed is too sharp, stone the corner slightly.
PROBLEM: Corners of Staple are Rounded
SOLUTION: The Swivel is worn and needs to be replaced.
PROBLEM: Loose Clinch
SOLUTION: The thickness of work adjustment setting is wrong, the Clinchers
are set too low. Correct the adjustment setting and raise the Clincher Points
(refer to pages 5 and 6).
PROBLEM: Tight Clinch
SOLUTION: The thickness of work adjustment setting is wrong, the Clinchers
are set too high. Correct the adjustment setting and lower the Clincher Points
(refer to pages 5 and 6).
PROBLEM: Staple Legs are Spread
SOLUTION: The Wire Straighteners are not properly adjusted or the Wire
Cutters and Bender Bar are worn. Adjust the Wire Straighteners (refer to
page 4). Reverse or replace the Wire Cutters or replace the Bender Bar (refer
to page 6).
PROBLEM: Staple Legs are Contracted
SOLUTION: The Wire Straighteners are not properly adjusted or the Wire
Cutters are worn.
