DEMA Nitro Plus User Manual

I-1205
Rev. B-43816
Page 11 of 13
3/23/2018
3 Roller Fixed – Roller Block
(Rinse/Sanitizer Pump)
Spring Loaded - Roller Block
(Detergent Pump)
Squeeze Tube
(See Common Replacement Parts on page 12)
DetergentPumpParts
Item
No.
DEMAKitNo. Description
1  81.173.12 DetergentPumpAssyw/60RPMMotor(noenclosure)
2  41.40.2 #6‐32x1/2"StainlessSteelScrew
3  81.174.1 BluePumpCover
4  81.128.2 BluePumpBase
5  81.172.1 SpringLoadedRollerBlockAssembly
6  25.85.2 #10‐32x1/2"StainlessSteelScrew
7  80.59.60MK.1 60RPMDetergentPumpMotorKit
8  81.47.1 1/2"HolePlug(notshown,plugsunused1/2"holesonbackofenclosures)
9  81.118.15 DetergentPumpKit‐BluePumpParts&RollerBlockAssy,nomotor
10 25.85.19 #10‐32x2"StainlessSteelScrew
Rinse/SanitizerPumpParts
Item
No.
DEMAKitNo. Description
1  81.173.7 Rinse/SaniPumpAssyw/15RPMMotor(noenclosure)
2  41.40.2 #6‐32x1/2"StainlessSteelScrew
3  81.174.1 BluePumpCover
4  81.128.2 BluePumpBase
5  81.172.2 3RollerFixed‐RollerBlockAssembly
6  25.85.2 #10‐32x1/2"StainlessSteelScrew
7  80.59.15MK.1 15RPMRinse/SanitizerPumpMotorKit
8  81.47.1 1/2"HolePlug(notshown,plugsunused1/2"holesonbackofenclosures)
9  81.118.16 Rinse/SaniPumpKit‐BluePumpParts&RollerBlockAssy,nomotor
10 25.85.19 #10‐32x2"StainlessSteelScrew
