I-1205
Rev. B-43816
Page 2 of 13
3/23/2018
Note:Left to Right- 1st Position Detergent,
2nd Position Rinse, 3rd Position Sanitizer
L = Liquid (pump)
D = DRY (solenoid valve)
Liquid or Dry Chemical Product
Nitro Plus
Base Unit
Nitro Express Models
Nitro Plus can be built in a number of configurations. The following applies to all systems.
Prewired with power, trigger and probe cables.
Mounting bracket assembled to the Nitro Plus and ready to use.
Appropriate installation kit items that include, fittings, tubing, etc. (see Packout Kit section)
NP.DLL.TI
Trigger Device
T = Trigger Board
M = Magnetic Field Sensor
Packing Kit List
NitroPlusInstallationKit
Part
Number
Description
Qty/Model
NP.DL.T
NP.LL.T
NP.DLL.T
NP.LLL.T
904.8T
RinseCheckValve(StainlessSteel)
1
1
1
1
904.8KY
SanitizerCheckValve(Kynar)
1
1
80.55
LiquidDetergentBulkheadFitting
1
1
58.5
DryDetergentBulkheadFitting
1
1
C.12VIK
ConductivityProbe(FlipProbe)
1
1
1
1
25.68.20
1/4"ODLDPETubing‐20ft
1
1
1
1
100.12.SV1
VinylRinseTube‐16ft
1
1
2
3
81.312.1
SplitPickupTubeStiffener
1
2
2
3
81.182.1
1/4"x1/4"Push‐OnFittings(forpump)
2
4
4
6
81.16.1
TieWraps8"Long
5
5
8
8
I‐1205
InstructionSheet
1
1
1
1
Strain Relief
System will come with strain relief for the
wiring that is exiting the enclosure.
Systems that do have the "I" come
with a 1/2" conduit.
