Page #9 background imageLoading...
Page #9 background image
I-1205
Rev. B-43816
Page 9 of 13
3/23/2018
NitroPlusControlModuleReplacementParts
Item
No.
DEMAKit
No.
Description
1
81.1 MountingBracketKit(includes2pcs,81.19.1,#8FlatHeadScrew)
2
81.501 MountingPanel(fortriggerboard)
3
81.499 ControlPanelCover
4
84.500 BaseBracket(forpowersupply)
5
84.501 CoverBracket(forpowersupply)
6
41.40.2 #6‐32x1/2"Screw
7
41.69.2 #6x1/2"SSSheetMetalScrew
8
44.116.2 #8x1/2"HiLoScrew(forplastic)
9
81.118.11.2 TriggerBoardKit
10
81.118.12 TriggerCableKit(triggerboardtocontrolboard,2pcsinkit)
11
81.163.1 PowerSwitch
12
81.18.1 #6x3/8"HiLoScrew(forplastic)
13
81.181.2 ProbeCable
14
84.176.1 StrainRelief
15
81.19.1 #8FlatHeadScrew
16
81.20.2 #4x3/8"HiLoScrew
17
81.118.42 Nitro ControlBoard
18
81.320.4 Power/TriggerCableAssembly(external power&trigger)
19
81.47.1 1/2"HolePlug
20
84.125.4 PowerSupplyCable
21
84.154.1 PowerSupply115/230VAC,24VDC,2.5A60W
22
84.195.3 EnclosureBack
23
84.206.3 Enclosure
24
84.298.1 24VDCPowerAdapter(barreljacktomodularcon nec tor)
25
L1113 MembraneLabel
26
L1123 DisplayLabel
27
L1715 NitroPlusLabel
28
84.183.7 CableStrainRelief
29
81.47.4 7/8"HolePlug
30
L947‐4 TriggerWireColorsLabel
