DENAFRIPS Ares - 4. Specifications; 5. Warranty and Supports

COPYRIGHT © DENAFRIPS
5 | P a g e |
V 5 . 0 | 2 4
t h
N o v 2 0 1 7
4. SPECIFICATION
Description Parameters
AC Power 115/230V, 50/60Hz
Power Consumption < 30W
Frequency Response 0-70K Hz(-3dB)
THD+N ≤0.004%(1KHz A-weighted)
Output (RCA) 2.2(+/-10%) V RMS(1KHz)
Output (XLR) 4.4(+/-10%) V RMS(1KHz)
Supported Format (DSD)
2.8224MHz(DSD1X) All Input
5.6448MHz(DSD2X), 11.288MHz(DSD4X) USB Only
Supported Format (PCM) 24bit/44.1, 48, 88.2, 96, 176.4, 192, 352.8(USB), 384(USB) kHz
S/N Ratio 115dB(RCA), 114dB(XLR)
Dynamic Range >119dB(RCA), >120dB(XLR)
Stereo Crosstalk ≤-124dB(RCA), ≤130dB(XLR)
Dimension 215 *230 *45 mm
Weight 3.5kg
5. WARRANTY & SUPPORTS
DENAFRIPS Ares comes with 36 months of warranty from the date of purchase / delivery
(whichever later). Customers shall bear the two-way shipping cost for RMA. In event of
tampering found on the unit, the warranty shall be voided.
Visit our website at www.denafrips.com for more updates
Enjoy The Music!
