Figure 2. Read Panel
Description:
(1) AC Power Supply
CAUTION! IRIS supports AC mains range from 100-250VAC. Please check the voltage switch
underneath the DDC, switch it to the correct voltage before connecting the AC mains.
(2) Digital Input Interface
IRIS support USB input only.
(3) Digital Output Interface
There are 5 Digital Output Interfaces, namely, COAX, AES, OPT, I2S-A, I2S-C. All outputs are
active simultaneously.
I2S-A HDMI (LVDS) I2S-C RJ45 (LVCMOS)
4
