DENAFRIPS PONTUS - 4. SPECIFICATION; 5. WARRANTY & SUPPORTS

COPYRIGHT © DENAFRIPS 8 | P a g e |
V 3 . 0 | 2 4
t h
N o v 2 0 1 7
4. SPECIFICATION
Description Parameters
AC Power
Worldwide AC Power Supported 110 - 230V, 50/60Hz
In 110VAC supply, the min voltage range from 92V to max 126V
In 230VAC supply, the min voltage range from 184V to max 253V
Power Consumption < 30W
Frequency Response 0-70K Hz(-3dB)
THD+N ≤0.0025% (1KHz A Weighted)
Output (RCA) 2.2(+/-10%) V RMS(1KHz)
Output (XLR) 4.4(+/-10%) V RMS(1KHz)
Supported Format (DSD)
2.8224MHz(DSD1X) All Input
5.6448MHz(DSD2X), 11.288MHz(DSD4X) USB & I2S Only
Supported Format (PCM)
24bit/44.1, 48, 88.2, 96, 176.4, 192,
352.8(USB & I2S), 384(USB & I2S) kHz
S/N Ratio 115dB(RCA), 114dB(XLR)
Dynamic Range >117dB (RCA), >121dB(XLR)
Stereo Crosstalk ≤-100dB(RCA), ≤100dB(XLR)
Dimension 320 *330 *80 mm
Weight 8.5kg
5. WARRANTY & SUPPORTS
DENAFRIPS Pontus comes with 36 months of warranty from the date of purchase / delivery
(whichever later). Customers shall bear the two-way shipping cost for RMA. In event of
tampering found on the unit, the warranty shall be voided.
Visit our website at www.denafrips.com for more updates
Enjoy The Music!
