FRONT WHEEL / BRAKE5
Your bike has a Bolt On mechanism
Tighten nuts securely to the fork dropouts
Multi Tool
5mm allen key
1. Remove Packing Block from disc brake
caliper,do NOT throw away, save and
re-install packing block whenever you remove
your front wheel.
4. Tighten one axle nut part way then tighten
the other nut, repeat until both sides are
tightened securely. Be sure that the wheel is
centered between the fork legs.
2. Position the front wheel so it’s centered
between the front fork legs with the axle
resting inside the fork drop outs.
3. Align the disc brake rotor so it is
centered in the slot of the brake caliper.
WARNING
Do NOT touch the brake rotor, especially while in motion.
Be CAUTIOUS and do not allow oils to be applied or added to the DISC/
ROTOR. This can cause squeaking and decrease braking performance.
Improper installation of the front wheel and or handlebar stem can cause loss of
control, accidents, serious injury or death. Check regularly that the front wheel
and handlebar stem are ALWAYS properly secure and in good working condition.
