CAIRplus Electrical Connection
PR-2009-0096-GB • Subject to modifications • R8-10/2015 53
7.2.3 Frequency inverter
Make the parameter settings in the course of unit start-up.
7.2.4 EC Fans
EC fans and motors provide air movement with the highest efficiency factor. Highly effi-
cient electronically commuted motors with permanent magnets are used with variable
speeds via integrated controller.
Connect the fans according to the attached documentation/wiring diagram and
observe the manufacturer's instructions.
When using earth leakage circuit breakers, make sure that they are sensitive to
universal current (type B).
If the control cables are wired to a terminal box, observe the pin assignment shown
in the following wiring diagram:
7.2.5 Service switch
Install a lockable service switch near the access door of the fan chamber.
When there is a factory-mounted service switch, the wiring is run up to the motor.
ATTENTION
Risk of damage to the unit!
Do not activate the parameter "overmodulation" as this can damage the impeller.
Permanent magnet motors (PM motor) without integrated electronics may only
be connected to suitable frequency inverters.
It is not possible to operate several PM motors with one frequency inverter.
Notice!
In this case, DencoHappel neither accepts warranty claims nor assumes liability.
Ensure that the maximum frequency does not exceed the allowable limit (refer
to data sheet on fan).
Consider the relevant instructions specified in the enclosed manual for the
frequency inverter. Use a screened motor cable only.
