Output audio signal from each Speaker Terminal
Refer to the following table, use the Speaker terminals that output the same signal and make a bi-amp connection.
Speaker layout
Speaker terminal
FRONT R FRONT L CENTER
SURROUND
R
SURROUND
L
SURROUND
BACK R
SURROUND
BACK L
FRONT
WIDE R
FRONT
WIDE L
HEIGHT 1
R
HEIGHT 1
L
HEIGHT 2
R
HEIGHT 2
L
HEIGHT 3
R
HEIGHT 3
L
HEIGHT 4
R
HEIGHT 4
L
5.1ch + Surround
Back
Front R Front L Center Surround Surround L
Surround
Back R
Surround
Back L
Front R Front L Not Used Center Surround R Surround L
Surround
Back R
Surround
Back L
Not Used Not Used
5.1ch + Front Wide Front R Front L Center Surround Surround L
Front Wide
R
Front Wide
L
Front Wide
R
Front Wide
L
Not Used Center Surround R Surround L Front R Front L Not Used Not Used
5.1ch + Height Front R Front L Center Surround Surround L Height R Height L Front R Front L Height R Height L Surround R Surround L Not Used Center Not Used Not Used
