7.1-channel playback : Bi-amp connection of all speakers
This system plays back 7.1-channels.
Bi-amp connections are available for all the speakers.
SW
C
SL
SBL
SR
SBR
FL
(Bi-Amp)
(Bi-Amp)
(Bi-Amp) (Bi-Amp)
(Bi-Amp) (Bi-Amp)
FR
(Bi-Amp)
0
In addition to the 7.1ch system with surround back speakers, you can make it into
a 7.1ch system that uses use front wide or height speakers. To configure this, set
“Amp Assign” - “Assign Mode” to “7.1ch Full Bi-Amp”, and then set “Floor” and
“Height” according to the speakers you are using. (v p. 214)
0
For the “7.1ch Full Bi-Amp” setting, the connection terminals vary according to the
speaker layout you are using. Connect them by referencing the following table.
Contents Connections Playback Settings Tips Appendix
62
Front panel Display Rear panel Remote Index

Denon AVC-A1H Specifications

General

Channels	15.4
Power Output	150W per channel (8 ohms, 20Hz-20kHz, 0.05% 2ch Drive)
HDMI Outputs	3
Audio Formats	Dolby Atmos, DTS:X, Auro-3D, IMAX Enhanced
Wireless Connectivity	Wi-Fi, Bluetooth
Type	AV Amplifier
IMAX Enhanced	Yes
8K/60Hz Pass-through	Yes
4K/120Hz Pass-through	Yes
HDR Support	HDR10, HDR10+, Dolby Vision, HLG
eARC	Yes
Phono Input	Yes
THD	0.05%
Frequency Response	10 Hz - 100 kHz
Input Sensitivity	200 mV
Signal-to-Noise Ratio	102 dB
Ethernet	Yes
USB Port	Yes
Multi-Room Audio	HEOS
Amplifier Type	Class AB
