Denon AVC-A1H User Manual

Connecting 13.1-channel speakers : Second pair of front speakers
This system enables switching playback between front speakers A and B
as desired.
C
SW
RSLS
FHL FHR
RHL RHR
SBL
SBR
FL
(A)
FL
(B)
FR
(B)
FR
(A)
TML TMR
CSRSL
SBR SBL
FR
(B)
FHR FHL RHR RHL
FL
(B)
FR
(A)
FL
(A)
TMR TML
z
2
z
2
z
2
z
2
z
2
z
2
z
1
z
1
SW
z
1
The speaker terminals for connecting to the second front speakers vary
depending on the MAIN ZONE layout. Refer to “Amp Assign” - “Front B”.
(v p. 223)
z2
The height speakers, ceiling speakers and Dolby Atmos Enabled speakers
can be connected to the HEIGHT1, HEIGHT2 and HEIGHT3 speaker
terminals. Set the speaker to be connected from “Height” in the menu.
(v p. 217)
Contents
Connections Playback Settings Tips Appendix
64
Front panel Display Rear panel Remote Index

Denon AVC-A1H Specifications

General

Channels	15.4
Power Output	150W per channel (8 ohms, 20Hz-20kHz, 0.05% 2ch Drive)
HDMI Outputs	3
Audio Formats	Dolby Atmos, DTS:X, Auro-3D, IMAX Enhanced
Wireless Connectivity	Wi-Fi, Bluetooth
Type	AV Amplifier
IMAX Enhanced	Yes
8K/60Hz Pass-through	Yes
4K/120Hz Pass-through	Yes
HDR Support	HDR10, HDR10+, Dolby Vision, HLG
eARC	Yes
Phono Input	Yes
THD	0.05%
Frequency Response	10 Hz - 100 kHz
Input Sensitivity	200 mV
Signal-to-Noise Ratio	102 dB
Ethernet	Yes
USB Port	Yes
Multi-Room Audio	HEOS
Amplifier Type	Class AB
