Layout
Set the speaker layout when installing 1 set (2-channels) of Height, Ceiling or Dolby Atmos Enabled speakers.
The layouts that can be selected differ depending on the combinations of “Assign Mode” and “Floor” in the menu. (“Assign Mode” (v p. 213),
“Floor” (v p. 215))
[2-channel heigh speakes]
Settings AUDIO OUT connectors
Height Sp Dolby Sp Layout HEIGHT 1 HEIGHT 2 HEIGHT 3 HEIGHT 4
None None - - - - -
2ch None
Front Height Front Height - - -
Top Front Top Front - - -
Top Middle Top Middle - - -
Top Rear Top Rear - - -
Rear Height Rear Height - - -
None 2ch
Front Dolby Front Dolby - - -
Surround Dolby Surround Dolby - - -
Back Dolby z Back Dolby z
- - -
z This can be selected when using Surround Back speakers. Set “Floor” in the menu to “5ch & SB” or “5ch & SB & FW”. (v p. 215)
