Front Layout / Middle Layout / Rear Layout
Set the speaker layout when installing 2 sets (4-channels) or more of Height, Ceiling or Dolby Atmos Enabled speakers.
The layouts that can be selected differ depending on the combinations of “Assign Mode” and “Floor” in the menu. (“Assign Mode” (v p. 213),
“Floor” (v p. 215))
[4-channel heigh speakes]
Settings AUDIO OUT connectors
Height Sp Dolby Sp NOTE Front Layout Rear Layout HEIGHT 1 HEIGHT 2 HEIGHT 3 HEIGHT 4
4ch None
Front Height Top Middle Front Height Top Middle - -
Front Height Top Rear Front Height Top Rear - -
Front Height Rear Height Front Height Rear Height - -
Front Height Surround Height Front Height Surround Height - -
Top Front Top Rear Top Front Top Rear - -
Top Front Rear Height Top Front Rear Height - -
Top Middle Rear Height Top Middle Rear Height - -
2ch 2ch
Front Height Surround Dolby Front Height Surround Dolby - -
Front Height
Back Dolbyz1
Front Height Back Dolby - -
Top Front Surround Dolby Top Front Surround Dolby - -
Top Front Back Dolby Top Front Back Dolby - -
Front Dolby Top Rear Front Dolby Top Rear - -
Front Dolby Rear Height Front Dolby Rear Height - -
None 4ch
Front Dolby Surround Dolby Front Dolby Surround Dolby - -
Front Dolby
Back Dolbyz1
Front Dolby Back Dolby - -
Contents Connections Playback Settings Tips Appendix
218
Front panel Display Rear panel Remote Index

Denon AVC-A1H Specifications

General

Channels	15.4
Power Output	150W per channel (8 ohms, 20Hz-20kHz, 0.05% 2ch Drive)
HDMI Outputs	3
Audio Formats	Dolby Atmos, DTS:X, Auro-3D, IMAX Enhanced
Wireless Connectivity	Wi-Fi, Bluetooth
Type	AV Amplifier
IMAX Enhanced	Yes
8K/60Hz Pass-through	Yes
4K/120Hz Pass-through	Yes
HDR Support	HDR10, HDR10+, Dolby Vision, HLG
eARC	Yes
Phono Input	Yes
THD	0.05%
Frequency Response	10 Hz - 100 kHz
Input Sensitivity	200 mV
Signal-to-Noise Ratio	102 dB
Ethernet	Yes
USB Port	Yes
Multi-Room Audio	HEOS
Amplifier Type	Class AB
