Denon AVC-A1XV Service Manual

150
AVR-5805/AVC-A1XV
00D1U-3645B D.VIDEO P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101,102 00D 262 3416 901 BR24L02F-WE2
IC103 00D 262 3431 009 SII9031
IC104 00D 263 1079 903 BA033FP +C
IC105 00D 262 3265 903 LM1117MPX-1.8 +C
IC106,107 00D 262 3120 909 SN65LVDS31PW +REF
IC108 00D 262 3432 901 SN65LVDS1DBVR
IC109 00D 263 1079 903 BA033FP +C
IC201,202 00D 262 3416 901 BR24L02F-WE2
IC203 00D 262 3431 009 SII9031
IC204 00D 263 1079 903 BA033FP +C
IC205 00D 262 3265 903 LM1117MPX-1.8 +C
IC209 00D 263 1079 903 BA033FP +C
IC301 00D 263 1079 903 BA033FP +C
IC302 00D 262 3265 903 LM1117MPX-1.8 +C
IC303 00D 262 3364 008 SII9030
IC304 00D 262 2977 933 BA50BC0FP-E2
IC306 00D 262 3410 907 TC74VHCT08AFT
IC351 00D 263 1079 903 BA033FP +C
IC352 00D 262 3265 903 LM1117MPX-1.8 +C
IC353 00D 262 3364 008 SII9030
IC401-405 00D 263 1082 903 TK15420MTL +C
IC406 00D 262 3417 007 AN13310BA
IC407,408 00D 263 1079 903 BA033FP +C
IC409 00D 262 3290 907 PQ015EZ5MZ +REF
IC410 00D 262 3429 008 MN673747HL
IC411 00D 262 3454 905 TC74VCX04FT
IC412 00D 262 3421 909 FCXO-03L(27.000MHz)
IC413 00D 262 3452 004 K4S161622H-TC60
IC414 00D 262 3440 003 TE8200PF
IC601 00D 262 3239 007 FLI2310-BC/BD +C
IC602 00D 262 3303 001 K4S643232#-TC60 +REF
IC603 00D 262 3265 903 LM1117MPX-1.8 +C
IC604-606 00D 263 1079 903 BA033FP +C
IC607 00D 263 1183 909 NJU7223DL1-25 +C
IC608 00D 262 3290 907 PQ015EZ5MZ +REF
IC609 00D 262 3438 002 TC90101FG
IC614-617 00D 262 2641 900 SN74LV541APW-EL2 +C
IC701 00D 263 1079 903 BA033FP +C
IC702 00D 263 1183 909 NJU7223DL1-25 +C
IC703 00D 262 3478 004 ADV7320
IC704 00D 262 3414 903 TC74LCX157FT
IC705 00D 263 1198 907 LT1399CS +REF
IC801 00D 263 1079 903 BA033FP +C
IC802 00D 263 1183 909 NJU7223DL1-25 +C
IC803 00D 262 3478 004 ADV7320
IC804 00D 263 1158 905 BH7862F +C
IC901 00D GEN 6811 VIDEO CPU SUB ASS'Y M30625FGPGP
IC902 00D 262 3424 906 LTC1694CS5
IC903 00D 262 3425 905 LTC4300-2CMS8
IC904 00D 263 1079 903 BA033FP +C
IC905 00D 263 1078 904 BA05FP +C
IC906 00D 262 3436 907 TC74VHC244FT
IC907 00D 262 3437 906 TC74VHCT244AFT
IC908 00D 262 3443 903 SN65LVDS050PWR
IC909 00D 262 3433 900 SN65LVDS2DBVR
TR101-103 00D 275 0110 905 HN1K02FU-TE85L
TR105 00D 269 0193 901 KRC104S-RTK(47K-47K) +C
TR107-110 00D 269 0193 901 KRC104S-RTK(47K-47K) +C
TR111 00D 269 0184 907 KRA102S-RTK +C
TR112 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR113 00D 269 0184 907 KRA102S-RTK +C
TR114 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR115 00D 275 0110 905 HN1K02FU-TE85L
