AVR-3802/1082
4 1U-3318 AMP connect unit Ass'
y
for EU,EC 1 4 1U-3318G AMP connect unit Ass'
y
for EU,EC,1082EU 1
1U-3318 A for E1,E1H 1U-3318 K for E1,E1H
1U-3318 B for E2 1U-3318 J for E2
1U-3318 E for EUT,E1C 1U-3318 L for EUT,E1C
4-1 1U-3318-1 AMP connect unit 4-1 1U-3318G-1 AMP connect unit
4-2 1U-3318-2 PRE OUT unit 4-2 1U-3318G-2 PRE OUT unit
4-3 1U-3318-3 S-video unit 4-3 1U-3318G-3 S-video unit
4-4 1U-3318-4 P.SW & H/P unit 4-4 1U-3318G-4 P.SW & H/P unit
4-5 1U-3318-5 Tuner unit 4-5 1U-3318G-5 Tuner unit
5 1U-3319 Regulator unit Ass'y for EU,EC 1 5 1U-3319G Regulator unit Ass'y for EU,EC,1082EU 1
1U-3319 A for E1,E1H 1U-3319 K for E1,E1H
1U-3319 B for E2,E1C 1U-3319 J for E2,E1C
1U-3319 E for EUT 1U-3319 M for EUT
5-1 1U-3319-1 Regulator unit 5-1 1U-3319G-1 Regulator unit
5-2 1U-3319-2 C.video unit 5-2 1U-3319G-2 C.video unit
5-3 1U-3319-3 COMP.video unit 5-3 1U-3319G-3 COMP.video unit
5-4 1U-3319-4 Digital In-1 unit 5-4 1U-3319G-4 Digital In-1 unit
5-5 1U-3319-5 Digital In-2 unit 5-5 1U-3319G-5 Digital In-2 unit
5-6 1U-3319-6 Holder unit 5-6 1U-3319G-6 Holder unit
5-7 1U-3319-8 PT903 unit 5-7 1U-3319G-8 PT903 unit
5-8 1U-3319-9 PT902 unit 5-8 1U-3319G-9 PT902 unit
5-11 1U-3319-11 Voltage select-1 unit for E1,E1H 5-11 1U-3319K-11 Voltage select-1 unit for E1,E1H
5-12 1U-3319-12 Voltage select-2 unit for E1,E1H 5-12 1U-3319K-12 Voltage select-2 unit for E1,E1H
6 1U-3320 AUDIO/DSP unit Ass'y for EU,EC 1 6 1U-3320G AUDIO/DSP unit Ass'y for EU,EC,1082EU 1
1U-3320A for E1,E1H,E1C 1U-3320 K for E1,E1H,E1C
1U-3320 B for E2 1U-3320 J for E2
1U-3320E for EUT 1U-3320M for EUT
12 4124716001 Support bracket 1 12 4124716001 Support bracket 0
23 1051353103 Back panel for EU,EC 1 23 1051381007 Back panel for EU,EC 1
1051353129 Back panel for E2 1 1051381010 Back panel for E2 1
1051353132 Back panel for E1,E1H 1 1051381023 Back panel for E1,E1H 1
1051353158 Back panel for E1C 1 1051381036 Back panel for E1C 1
1051353145 Back panel for EUT 1 1051381049 Back panel for EUT 1
1051381078 Back panel for 1082EU
25 1442745003 Front panel Ass'y for EU,EC 1 25 1442770007 Front panel Ass'y for EU,EC 1
1442745032 Front panel Ass'y (BK) for E2 1 1442770023 Front panel Ass'y (BK) for E2 1
1442745045 Front panel Ass'y (G) for E2 1 1442770036 Front panel Ass'y (G) for E2 1
1442745029 Front panel Ass'y for E1,E1H,EUT,E1C 1 1442770049 Front panel Ass'y for E1,E1H,EUT,E1C 1
1442770052 Front panel Ass'y for 1082EU
26 1462221002 Inner panel Ass'y for EU,EC 1 26 1462221138 Inner panel Ass'y(BK) for EU,EC,E2 1
1462221015 Inner panel Ass'y for E2,E1,E1H,EUT,E1C 1 1462221141 Inner panel Ass'y(G) for E2,E1,E1H,EUT,E1C 1
1462221154 Inner panel Ass'y(BK) for 1082EU
42 2336352006 Power trans for EU,EC,EUT 1 42 2336363008 Power trans for EU,EC,EUT,1082EU 1
2336356002 Power trans for E2 1 2336364007 Power trans for E2 1
2336357001 Power trans for E1,E1H 1 2336365006 Power trans for E1,E1H 1
2336317009 Power trans for E1C 1 2336366005 Power trans for E1C 1
54 4610976025 Rubber sheet Top cover 1
SCREWS SCREWS
101 4737002005 Screw 3X6 CBTS (S)-Z 10 101 4737002005 Screw 3X6 CBTS (S)-Z 0
103 4737005002 Screw 3X10 CBTS (S)-Z 29 103 4737005002 Screw 3X10 CBTS (S)-Z 28
114 4718010100 Special screw Power unit 1
Note: The symbols in the column "Remarks" indicate the following destinations.
EU: U.S.A. model E1C: China model
EC: Canada model E1H: Hong Kong model
E2: Europe model EUT: Taiwan R.O.C.model
E1: Asia model
PARTS LIST OF EXPLODED VIEW
AVR-3801 AVR-3802/1082
Ref. No. Part No. Part name Remarks Q't
y
Ref. No. Part No. Part name Remarks Q't
y
1 1U-3315 Power unit Ass'y for EU,EC 1 1 1U-3315G Power unit Ass'y for EU,EC,1082EU 1
1U-3315 A for E1,E1H 1U-3315 K for E1,E1H
1U-3315 B for E2 1U-3315 J for E2
1U-3315 E for EUT 1U-3315 M for EUT
1U-3315 F for E1C 1U-3315 L for E1C
1-1 1U-3315-1 Power unit 1-1 1U-3315G-1 Power unit
1-2 1U-3315-2 SP F unit 1-2 1U-3315G-2 SP F unit
1-3 1U-3315-3 SP S unit 1-3 1U-3315G-3 SP S unit
2 1U-3316 EXT.IN unit Ass'y for EU,EC 1 2 1U-3316G EXT.IN unit Ass'y for EU,EC,1082EU 1
1U-3316 A for E1,E1H,E1C 1U-3316 K for E1,E1H,E1C
1U-3316 B for E2 1U-3316 J for E2
1U-3316 E for EUT 1U-3316 M for EUT
2-1 1U-3316-1 Display unit 2-1 1U-3316G-1 Display unit
2-2 1U-3316-2 EXT IN VR unit 2-2 1U-3316G-2 EXT IN VR unit
2-3 1U-3316-3 VOL. unit 2-3 1U-3316G-3 VOL. unit
2-4 1U-3316-4 Power SW unit for E1,E1H,E1C,EUT,E2 2-4 1U-3316K-4 Power SW unit for E1,E1H,E1C,EUT,E2
3 1U-3317 Control unit Ass'y for EU,EC 1 3 1U-3338G Control unit Ass'y for EU,EC,1082EU 1
1U-3317 A for E1,E1H 1U-3338 K for E1,E1H
1U-3317 B for E2 1U-3338 J for E2
1U-3317 E for EUT 1U-3338 M for EUT
1U-3317 F for E1C 1U-3338 L for E1C
3-1 1U-3317-1 Control unit 3-1 1U-3338G-1 Control unit
3-2 1U-3317-2 Connect unit 3-2 1U-3338G-2 Connect unit
3-3 1U-3317-3 Front unit 3-3 1U-3338G-3 Front unit
PARTS LIST OF PACKING ACCESSORIES
AVR-3801 AVR-3802/1082
Ref. No. Part No. Part name Remarks Q't
y
Ref. No. Part No. Part name Remarks Q't
y
203 5113663009 Inst manual (E3) for EU,EC 1 203 5113785107 Inst manual (EU) for EU,EC 1
5113729008 Inst manual (EC) for EC 1 5113786106 Inst manual (EC) for EC 1
5113709002 Inst manual (E2) for E2 1 5113803005 Inst manual (E2) for E2 1
5113708003 Inst manual (E1) for E1,E1H,EUT 1 5113804004 Inst manual (E1) for E1,E1H,EUT 1
5113710004 Inst manual (E1C) for E1C 1 5113805003 Inst manual (E1C) for E1C 1
5113884008 Inst manual (1082) for 1082EU 1
215 5012100029 Carton case for EU,EC,E1,E2,EUT 1 215 5012100058 Carton case for EU,EC,E1,E2,EUT 1
5012100032 Carton case for E1H 1 5012100061 Carton case for E1H 1
5012099059 Carton case for 1082EU 1
221 5133549006 Carton label (T) for EUT 1 221 5133549035 Carton label (T) for EUT 1
5133518008 Carton label
(
C
)
for E1C 1 5133518037 Carton label
(
C
)
for E1C 1
