Denon AVR-2113 Service Manual

155
Ref. No. Part No. Part Name Remarks Q'ty New
29 nsp BRACKET SIDE 401021068600DS 1
30 963451101130D SHEET PET CLEAR 1210211919000S 1 *
★
31 nsp DOUBLE TAPE A710000520000S -
32 963451101140D SHEET PET CLEAR FUNCTION
2113CIBKE3,
2113BKE2,
2113SPE1C
1210211939000S 1 *
33 nsp BRACKET HDMI 4010215226000S 1
34 nsp SUPPORTER(4.8mm) 4070211653000S 1
★
35 00D9960018706 TR 2SD2390-Y
"Q404, Q416,
Q428, Q440,Q452,
Q464, Q476"
J5032390Y0000S 7
★
36 00D9960018706 TR 2SB1560-Y
"Q410, Q422,
Q434, Q446, Q458,
Q470, Q482"
J5011560Y0000S 7
★
37 963219003340S TR 2SC KTC3964/TO126S-BULK
"Q409, Q421,
Q433, Q445, Q457,
Q469, Q481"
J502396400010S 7
★
38 963612504760D CABLE,FLAT CARD 1.0MM 1.0X23X230 N711232312480S 1 *
★
39 963612504770D CABLE,FLAT CARD 1.0MM 1.0X40X190 N711401912480S 1 *
★
40 nsp CLAMP CABLE 4330040343010S 6
★
41 nsp CLAMP WIRE(HOLDER L=50) 4330210189000S 1
★
42 544510081006M LABEL HOT-SURFACE
1913BKE3,
2113CIBKE3
5507000003730S 1
SCREWS
A nsp
SCREW
+2S 3X8 B-TYPE(DA CHENG) ZNW/BH
B020030081B10S 29
C nsp
SCREW
+2S 3X8(ROUND)(DA CHENG) BK/BH
B020230083B10D 43
D nsp
SCREW
+2
+ S 3X6(ROUND)BK/BH
B020230063B10S 6 *
G nsp
SCREW
+3S 4X10 P+S WASHER(ROUND)BK/BH
B028940101B11S 4
H nsp
SCREW
+2S 3X14 P(Φ6)+S-WASHER ZNY/HH
B018230141H11D 21 *
I nsp
SCREW
+2S 3X17 B-TYPE(DA CHENG) BK/BH
B020030171B10S 1
J nsp
SCREW
+2S 4X8 B-TYPE(DOT)(DACHENG) BK/BH
1913BKE3,
2113CIBKE3
1500040083B10S 6
J nsp
SCREW
+2S 4X8 B-TYPE(DOT)(DACHENG) BK/BH
2113BKE2 1500040083B10S 8
J nsp
SCREW
+2S 4X8 B-TYPE(DOT)(DACHENG) BK/BH
2113SPE1C 1500040084B10S 6
K nsp
SCREW
+2S 3X10 B-TYPE(DOT)(DA CHENG) BK/BH
1913BKE3,
2113BKE2,
2113SPE1C
B020030103B11D 23
K nsp
SCREW
+2S 3X10 B-TYPE(DOT)(DA CHENG) BK/BH
2113CIBKE3 B020030103B11D 25
L nsp
SCREW
+3S 3X6(DOT)CBTS(S)-B
1913BKE3,
2113CIBKE3,
2113SPE1C
B020930063B10S 10
L nsp
SCREW
+3S 3X6(DOT)CBTS(S)-B
2113BKE2 B020930063B10S 9

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
