Denon AVR-2113 Service Manual

191
Ref. No. Part No. Part Name Remarks Q'ty New
ZD404 963202500300D D,ZENER ZJ5.1A-0.5W K06005R134522S
ZD405,406 963202500280D D,ZENER ZJ3.3B-0.5W K06003R344522S
ZD407 963202500300D D,ZENER ZJ5.1A-0.5W K06005R134522S
ZD408,409 963202500280D D,ZENER ZJ3.3B-0.5W K06003R344522S
ZD410 963202500300D D,ZENER ZJ5.1A-0.5W K06005R134522S
ZD411,412 963202500280D D,ZENER ZJ3.3B-0.5W K06003R344522S
ZD413 963202500300D D,ZENER ZJ5.1A-0.5W K06005R134522S
ZD414,415 963202500280D D,ZENER ZJ3.3B-0.5W K06003R344522S
ZD416 963202500300D D,ZENER ZJ5.1A-0.5W K06005R134522S
ZD417,418 963202500280D D,ZENER ZJ3.3B-0.5W K06003R344522S
ZD419 963202500300D D,ZENER ZJ5.1A-0.5W K06005R134522S
ZD420,421 963202500280D D,ZENER ZJ3.3B-0.5W K06003R344522S
RESISTORS GROUP
R404 nsp R,FIXED 1WJ-5.6K N113135656220S
R404 nsp R,FIXED,M.O. RSD-R1-1WJ-4.7K 2113E2 N113135647230S
R406 963252100140D POSISTOR DHPTHF1608 471P F320471001050S
R408 nsp R,FIXED 1WJ-5.6K N113135656220S
R408 nsp R,FIXED,M.O. RSD-R1-1WJ-4.7K 2113E2 N113135647230S
R415 963125012630S R,METAL FILM 22-J,1W FLAME RETARDANT C060022065050S
R424,425 00D9630345903 R,FIXED 2WJ-0.47 FLAME RETARDANT N113136647820S
R430,431 00D9630345903 R,FIXED 2WJ-0.47 FLAME RETARDANT N113136647820S
R434 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R439 963125012630S R,METAL FILM 22-J,1W FLAME RETARDANT C060022065050S
R441 nsp R,METAL FILM 1.2K-J,1W C060012265050S
R443 nsp R,METAL FILM 47-J,1W C060047065060S
R445 nsp R,FIXED 1WJ-5.6K N113135656220S
R445 nsp R,FIXED,M.O. RSD-R1-1WJ-4.7K 2113E2 N113135647230S
R450 963252100140D POSISTOR DHPTHF1608 471P F320471001050S
R451 nsp R,FIXED 1WJ-5.6K N113135656220S
R451 nsp R,FIXED,M.O. RSD-R1-1WJ-4.7K 2113E2 N113135647230S
R458 963125012630S R,METAL FILM 22-J,1W FLAME RETARDANT C060022065050S
R467,468 00D9630345903 R,FIXED 2WJ-0.47 FLAME RETARDANT N113136647820S
R474,475 00D9630345903 R,FIXED 2WJ-0.47 FLAME RETARDANT N113136647820S
R478 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R483 963125012630S R,METAL FILM 22-J,1W FLAME RETARDANT C060022065050S
R485 nsp R,METAL FILM 1.2K-J,1W C060012265050S
R487 nsp R,METAL FILM 47-J,1W C060047065060S
R489 nsp R,FIXED 1WJ-5.6K N113135656220S
R489 nsp R,FIXED,M.O. RSD-R1-1WJ-4.7K 2113E2 N113135647230S
R493 00D9630337908 R,METAL 33-J,1W FLAME RETARDANT C060033065050S
R494 963252100140D POSISTOR DHPTHF1608 471P F320471001050S
R495 nsp R,FIXED 1WJ-5.6K N113135656220S
R495 nsp R,FIXED,M.O. RSD-R1-1WJ-4.7K 2113E2 N113135647230S
R502 963125012630S R,METAL FILM 22-J,1W FLAME RETARDANT C060022065050S
R511,512 00D9630345903 R,FIXED 2WJ-0.47 FLAME RETARDANT N113136647820S
R517,518 00D9630345903 R,FIXED 2WJ-0.47 FLAME RETARDANT N113136647820S
R521 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R526 963125012630S R,METAL FILM 22-J,1W FLAME RETARDANT C060022065050S
R528 nsp R,METAL FILM 1.2K-J,1W C060012265050S
R530 nsp R,METAL FILM 47-J,1W C060047065060S
R534 nsp R,FIXED 1WJ-5.6K N113135656220S
R534 nsp R,FIXED,M.O. RSD-R1-1WJ-4.7K 2113E2 N113135647230S
R537 963252100140D POSISTOR DHPTHF1608 471P F320471001050S
R538 nsp R,FIXED 1WJ-5.6K N113135656220S
R538 nsp R,FIXED,M.O. RSD-R1-1WJ-4.7K 2113E2 N113135647230S

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
