Denon AVR-2113 Service Manual

203
Ref. No. Part No. Part Name Remarks Q'ty New
CN4400 nsp CN.FPC 1.0MM 1.0-11S-40PW 40P L130100114050S
CN4402 nsp CN,WIRE 2MM 570MM/5P L002571050090S
CN4402 nsp CN,WIRE 2MM 500MM/5P 2113E2 L002501050040S
CP4400 nsp CN.WAFER 5268-07A 7P L102526800700S
CP4401 nsp CN.WAFER 7P L101100030710S
CP4402,4403 nsp CN.WAFER 7P L101100040710S
CP4405 nsp CN.WAFER 7P L101100030710S
CP4406 963643101610D CN,PLUG CONTACT USB G480040000180S
z
F4401 963652500020S FUSE 6125FF500-R 500mA G657612505030S
G4400 nsp RING,TER WIRE 160MM 8410161010120S
JACK4400 00D9630367802 JACK,D3.5 EARPHONE G401PJ354H40YS
JACK4401 963643101600D JACK,D6.5 PHONE (YUQIU) G402PJ621HA0YS
JACK4402 963643101640D TER,RCA 3PIN RCA-308H-11 G606308H1100YS
RMC4400 963262010290S MODULE,REMOCON R34FS9A E940349003810S
SW4400-4409 00D9630095305 SW,TACT SKHV10910D01 G180040500010S
SW4410 00D9630387408 SW,ENCODER EC16B24SO G121162400070S
SW4411 00D9630095305 SW,TACT SKHV10910D01 G180040500010S
SW4412 00D9630387408 SW,ENCODER EC16B24SO
2113CIE3, 2113E2,
2113E1C
G121162400070S
JP4401 nsp R,CHIP 0-J,1/8W C200000061300S
JP4402 nsp R,CHIP 0-J,1/8W C200000061300S
nsp BRACKET FIP 4010214916000S

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
