Denon AVR-2113 Service Manual

205
Ref. No. Part No. Part Name Remarks Q'ty New
CN4003 nsp
CN,WAFER C125Z2-11 11P BtoB
SOCKET(FEMALE) P=1.25MM
L109012521120S
CN4004 nsp
CN,WAFER C125Z2-17 17P BtoB
SOCKET(FEMALE) P=1.25MM
L109012521720S
CN4700 nsp CN,WAFER 9P C125Z2-09 2113CIE3 L109012520920S
CN4701 nsp CN.WAFER 13P C125Z2-13 2113CIE3 L109012521320S
CP4200 nsp CN,WAFER C125Z1-23 23P L109012512320S
CP4201 nsp CN.WAFER C125Z1-31 31P L109012513120S
CP4202 nsp CN,WAFER C125Z1-15 15P L109012511520S
CP4203 nsp CN,WAFER C125Z1-07 7P L109012510720S
JACK4200,4201 00D9630132103 TER,RCA 4PIN RCA-405B-04 G602405B0400YS
JACK4202 90M-YT004640R TER,RCA 2PIN RCA-207AE-02 2113CIE3 G601207AE020YS

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
