Denon AVR-2113 Service Manual

77
Input
CVBS
A
Check on set value of each IC.
Is they the following voltage
values?
HDMI B'D
CN3402-6pin : H(5V)
CN3402-7pin : L(0V)
CN3402-8pin : L(0V)
Is the power supply voltage
correctly output?
V+5V : C5003 : + side
V-5V : C5002 : - side
Is the signal output from the
video amplier?
V : J5008
Check power supply voltage
of IC5000 and IC5001, and
surrounding circuitry soldering.
Check cable between main
unit and monitor or check
monitor.
Is the signal input to selector
IC5001?
V : J5011
Check cable between main unit and
player or check player.
Extend HDMI B'D using a jig.
REGULATOR B'D aw.
HDMI B'D aw.
Check connection of FRONT
CONNECTOR BD and AV BD.
NO
NO
NO
NO NO
YES
YES
YES
YES
YES
b
Unless specied, VIDEO B'D part.
Is the power supply voltage
correctly output?
FRONT CONNECTOR B'D
V+5V : CN5001-9pin
V-5V : CN5001-13pin
q
e
w
r
t

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
