Denon AVR-2307 User Manual

60
AVR-2307CI / AVR-2307 / AVR-887 / AVC-1930
CP802 00D 205 1324 092 19P PIN HEADER(9120) L100912190010S
CP806 00D 205 1324 005 10P PIN HEADER(9120) L100912100010S
CP809 nsp 00D 963 0235 806 CN.WAFER 3P L101220030000S
CP906 nsp 00D 963 0235 903 CN.WAFER 4P L101220040000S
CP1105 nsp 00D 960 0239 609 CN.WAFER 13P L101100041310S
CP1106 nsp 00D 963 0087 805 CN.WAFER 11P L101100041110S
CP1502 nsp 00D 963 0087 805 CN.WAFER 11P L101100041110S
CP1503 00D 963 0256 908 CN.WAFER 10P L101100041010S
CP3001 00D 205 1324 005 10P PIN HEADER(9120) L100912100010S
CP3002 00D 205 1323 080 8P PIN HEADER(9120) L100912080010S
CP3003 00D 205 1324 005 10P PIN HEADER(9120) L100912100010S
CP3004 00D 205 1323 080 8P PIN HEADER(9120) L100912080010S
G301,302 00D 963 0257 509 RING,TER WIRE 80MM/1P 8410800010100S
GND01,02 - TERMINAL EARTH 3790040886000S
JACK301 00D 963 0158 307 JACK,DIN-416G G40341600000YS
L301 nsp 00D 960 0128 008 COIL INDUCTOR 100UH-Q40/9M D330101001020S
L361 nsp 00D 960 0215 908 COIL INDUCTOR 4.7UH-Q40/32M D3304R7001020S
RMC301 00D 963 0217 808 MODULE,REMOCON NJL34H380A E940343800010S
SW301C 00D 963 0200 103 SW,TACT SKHV10920A G180000270010S
SW302B 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW302B1 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW302C 00D 963 0200 103 SW,TACT SKHV10920A G180000270010S
SW303B 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW303B1 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW303C 00D 963 0200 103 SW,TACT SKHV10920A G180000270010S
SW304B 00D 963 0095 305 SW,TACT SKHV10910D01 Except for JP G180040500010S
SW304B1 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW304C 00D 963 0200 103 SW,TACT SKHV10920A G180000270010S
SW305B 00D 963 0095 305 SW,TACT SKHV10910D01 Except for JP G180040500010S
SW305B1 00D 963 0200 103 SW,TACT SKHV10920A G180000270010S
SW305C 00D 963 0200 103 SW,TACT SKHV10920A G180000270010S
SW306B 00D 963 0095 305 SW,TACT SKHV10910D01 Except for JP G180040500010S
SW306B1 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW306C 00D 963 0200 103 SW,TACT SKHV10920A G180000270010S
SW307B 00D 963 0095 305 SW,TACT SKHV10910D01 Except for JP G180040500010S
SW307C 00D 963 0200 103 SW,TACT SKHV10920A G180000270010S
SW308B 00D 963 0095 305 SW,TACT SKHV10910D01 Except for JP G180040500010S
SW308C 00D 963 0200 103 SW,TACT SKHV10920A G180000270010S
SW309B 00D 963 0095 305 SW,TACT SKHV10910D01 Except for JP G180040500010S
SW309C 00D 963 0200 103 SW,TACT SKHV10920A G180000270010S
VEC301 00D 963 0095 208 SW,ENCODER EC16B24SA G121162400040S
VEC302 00D 963 0300 401 SW,ENCODER EC11B20C2 G121112020000S
X201 00D 963 0217 701
RESONATOR,CERAMIC ZTT12.00MT
E830120000060S
XTAL201 00D 963 0217 604 CRYSTAL4.332MHZ,HC-49U E2,E2A E800433200100S
FLT301 00D 963 0300 906 DISPLAY,FLT 16-ST-87GINK K530168700010S
- HEAT SINK 2120210958000S
nsp 00D 963 0018 007 SCREW 3*8 B-TYPE ZNW/BH B020030081B10S
- HOLDER FLT 4320210536000S
JK301 00D 963 0146 403 TER,RCA 3PIN G606308HG110YS
00D 963 0257 509 RING,TER WIRE 80MM/1P 8410800010100S
Ref. No. nsp Part No. Part Name Remarks Q'ty New
