83
AVR-2307CI / AVR-2307 / AVR-887 / AVC-1930
C3261 00D 963 0224 008 C,CERAMIC 470PF-J/50V 2307CIE3,887E3 D010471167160S
C3262,3263 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V 2307CIE3,887E3 D011104577160S
C3264 00D 963 0323 909 C,CERAMIC 0.1UF-K/50V D011104177100S *
C3265 - C,CERAMIC 100PF-J/50V D011101167100S
C3266 00D 963 0323 909 C,CERAMIC 0.1UF-K/50V D011104177100S *
C3267 - C,CERAMIC 0.01UF-K/50V D011103177100S
C3268 - C,CERAMIC 1000PF-K/50V D011102177100S
C3271-3278 - C,CERAMIC 1000PF-K/50V D011102177100S
C3279-3286 - C,CERAMIC 100PF-J/50V D011101167100S
C3292 00D 963 0324 801 C,ELECT 10UF-MVG/25V 2307CIE3,887E3 D050100084200S *
C3293 - C,CERAMIC 1000PF-K/50V D011102177100S
C3298 00D 963 0323 909 C,CERAMIC 0.1UF-K/50V D011104177100S *
C3299 - C,ELECT 10UF-MVG/16V 2307CIE3,887E3 D050100083460S
C3300,3301 00D 963 0324 801 C,ELECT 10UF-MVG/25V D050100084200S *
C3302 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V 2307CIE3,887E3 D011104577160S
OTHERS PARTS GROUP
CB806,807 nsp 00D 963 0234 603 COIL,BEAD MB-160808 D340160800060S
CB3001-3008 nsp 00D 963 0234 603 COIL,BEAD MB-160808 D340160800060S
CN802 00D 205 1326 090 19P SOCKT(9120) L120912190010S
CN806 00D 205 1326 003 10P SOCKET(9120) L120912100010S
CN807 00D 963 0329 408 CN,WIRE 180MM/4P L000181040090S *
CN809 00D 963 0329 505 CN,WIRE 250MM/3P L000251030090S *
CN3001 00D 205 1326 003 10P SOCKET(9120) L120912100010S
CN3002 00D 205 1325 088 8P SOCKET(9120) L120912080010S
CN3003 00D 205 1326 003 10P SOCKET(9120) L120912100010S
CN3004 00D 205 1325 088 8P SOCKET(9120) L120912080010S
CN3005 00D 963 0329 806 CN,WIRE 510MM/11P L000511110010S *
CP3001A 00D 205 1378 909 18P FFC BASE(9610SD) L130961181010S
CP3002A 00D 205 1257 949 11P FFC BASE (9610SD L130961111010S
JACK3001-3003
00D 963 0330 507 CN.WAFER 19P L109425010190S *
JACK3004 00D 205 1362 009 XM/DT BUS CONNECTOR 2307CIE3,887E3 L109040000010S
L3007 00D 235 0125 905 INDUCTOR(FLC32C220K)+3216 D307252000220S
RL3001,3002 00D 214 0238 905 RELAY(UB2-12NUN-L1) G680120120010S
TP3002 00D 205 1343 950 7P FFC BASE(9610SC) L130961070010S
X3001 00D 399 1039 909 FCX-03(28.322MHZ) E80528R320010S
X3002 00D 399 1052 902 FCX-03(28.6363MHz) E80528R630010S
X3003 00D 399 1055 909 FCX-02(45.1584MHz) 2307CIE3,887E3 E80545R150010S
X3005 00D 399 1038 900 FCX-03(12MHZ) E805120000010S
XTAL1 00D 399 1053 901 FCX-03(24.576MHz) E80524R570010S
XTAL2 00D 399 1047 904 FCX-03(25MHZ) E805250000010S
Ref. No. nsp Part No. Part Name Remarks Q'ty New
