46
ENGLISH
Inputting characters
“Preset Name” (vpage49), “Rename” (vpage51), “Zone Rename”
(vpage65), and “Quick Select Name” (vpage65)can be changed as
desired.
For inputting characters, there are three methods, as shown below.
Method for inputting characters
Method Operations
Using the number
buttons
(normal screen)
Operating with the remote control unit.
Multiple characters are assigned to
a button, and each time the button is
pressed, a character is switched.
Using the cursor buttons
(normal screen)
Operating with the remote control unit
or the main unit.
Use
uio p and ENTER to input
characters.
Using the keyboard
screen
Operating with the remote control unit.
Select a character on the TV screen to
input characters.
Normal screen
n Display of a normal input screen
DVD
Default
INPUT SETUP
RENAME
RETURN CancelENTER,0-9 Enter
Input
a/A KeyboardSHIFT SEARCH
DVD
q
w
q Character input section
w Guide for operation buttons
Using the number buttons
1
Display the screen for inputting characters.
(vpage 44 “Menu map”)
2
Place the cursor at the character to be changed with
o p and press the number button (0 9) until the
desired character is displayed.
The types of characters that can be input are as shown below.
1 . @ - _ / : ˜ M N O m n o 6
A B C a b c 2 P Q R S p q r s 7
D E F d e f 3 T U V t u v 8
G H I g h i 4 W X Y Z w x y z 9
J K L j k l 5
0 (Space) ! “ # $ % & ‘ ( )
z
+ ,
; < = > ? [ \ ] ^ ` { | }
The input character type can be switched
by pressing
SHIFT while the display name
is being changed.
For entering the characters assigned to one
number button continuously, press p to
move the cursor to the right after entering
a character then enter the next character.
For entering characters assigned to
separate buttons, press the number button
continuously. The cursor automatically
moves to the next position, and the entered
character is registered.
3
Repeat step 2 to change the name then press ENTER
to register it.
Example: For changing the input source from “DVD” to “DENON”
q Place the cursor at “V”.
DVD
w Press
twice.
DED
“V” changes to “E”.
e Press
twice.
DEN
“E” is automatically registered, and “D” changes
to “N”.
r Press p.
DEN
“N” is registered.
t Press
three times.
DENO
Input “O”.
y Press p.
DENO
“O” is registered.
u Press
twice.
DENON
Input “N”.
i Press
ENTER to register the input source name.
Using the cursor buttons
1
Display the screen for inputting
characters.
(vpage 44 “Menu map”)
2
Use o p to set the cursor to the
character you want to change.
3
Use ui to change the character,
then press ENTER.
The types of characters that can be input are
as shown below.
GUpper case charactersH
ABCDEFGHIJKLMNOPQRSTUVWXYZ
GLower case charactersH
abcdefghijklmnopqrstuvwxyz
GSymbolsH ! “ # $ % & ‘ ( )
z
+ , - . / : ; < = > ? @ [ \ ] ^ _ ` { | } ˜
GNumbersH
0123456789 (Space)
The input character type can be switched by pressing
SHIFT while
the display name is being changed.
4
Repeat steps 2 and 3 to change the name then press
ENTER to register it.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-2311 and is the answer not in the manual?

Denon AVR-2311 Specifications

General IconGeneral
Frequency range10 - 100000 Hz
Audio output channels7.1 channels
Audio A/D Converter (ADC)24-bit/192kHz
Signal-to-Noise Ratio (SNR)100 dB
Power output per channel (20-20KHz@8 Ohm)135 W
HDMI in6
Audio (L/R) in8
Composite video in1
Component video (YPbPr/YCbCr) in2
Headphone connectivity6.3 mm
12V triggerYes
Connectivity technologyWired
Speakers connectivity type-
Ethernet LANNo
AM band range522 - 1611 kHz
FM band range87.5 - 108 MHz
Supported radio bandsAM, FM
Preset stations quantity56
Supported video modes1080p
DisplayLCD
Product colorBlack
Audio decodersDolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD
Apple docking compatibilityiPhone, iPod
AC input voltage230 V
AC input frequency50 Hz
Power consumption (standby)1.9 W
Power consumption (typical)600 W
Weight and Dimensions IconWeight and Dimensions
Depth381 mm
Width434 mm
Height171 mm
Weight11200 g
