Denon AVR-2311 - ZONE2 Setup options; Speaker Config. (Continued)

59
ENGLISH
Basic versionSimple version InformationAdvanced version
Manual Setup
Setting items Setting details
Bass Setting
Set subwoofer and LFE
signal range playback.
SW Mode : Select low range signals to be reproduced by subwoofer.
• LFE : The low range signal of the channel set to “Small” speaker size is
added to the LFE signal output from the subwoofer.
• LFE+Main : The low range signal of all channels is added to the LFE
signal output from the subwoofer.
• “SW Mode” can be set when “Speaker Config.” – “Subwoofer”
(vpage58) is set to “Yes”.
• Play music or a movie source and select the mode offering the strongest
bass.
• Select “LFE+Main” if you want the bass signals to always be produced
from the subwoofer.
NOTE
If “Front” and “Center” for “Speaker Config.” are set to “Large”, and “SW
Mode” is set to “LFE”, no sound may be output from the subwoofers,
depending on the input signal or selected surround mode.
LPF for LFE : Set LFE signal playback range.
• 80Hz / 90Hz / 100Hz / 110Hz / 120Hz / 150Hz / 200Hz / 250Hz
Distance
Set distance from listening
position to speakers.
Measure beforehand the
distance from the listening
position to each speaker.
Unit : Set the unit of distance.
• Meters / Feet
Step : Set the minimum variable width of the distance.
• 0.1m / 0.01m
• 1ft / 0.1ft
Front L / Front R / Center / Subwoofer / Surround L / Surround R /
S.Back L
z
/ S.Back R
z
/ F.Height L / F.Height R : Select the speaker.
z When the “Speaker Config.” – “S.Back” setting (vpage59) is set to
“1spkr”, “S.Back” is displayed.
• 0.00m – 18.00m / 0.0ft – 60.0ft : Set the distance.
• The speakers that can be selected differ depending on the “Amp Assign”
(vpage58) and “Speaker Config.” (vpage58) settings.
• Default settings :
Front L / Front R / Center / Subwoofer / F.Height L / F.Height R : 3.6 m
(12.0 ft)
Surround L / Surround R / S.Back L / S.Back R : 3.0 m (10.0 ft)
• Set the difference in the distance between the speakers to less than
6.0 m (20 ft).
NOTE
Speakers set to “None” in “Speaker Config.” (vpage 58) are not
displayed.
Remote control operation
buttons
Move the cursor
(Up/Down/Left/Right)
Confirm the setting Return to previous menu
Setting items Setting details
Speaker Config.
(Continued)
Surround : Set the presence and size of the surround speakers.
• Large : Use a large speaker that can adequately play back low
frequencies.
• Small : Use a small speaker that has inadequate playback capacity for
low frequencies.
• None : Select when the surround speakers are not connected.
• When “Surround” is set to “Large”, “S.Back” and “F.Height” can be
set to “Large”.
• When “Surround” is set to “None”, “S.Back” and “F.Height” can
automatically set to “None”.
S.Back : Set the presence, size and number of surround back speakers.
• Large : Use a large speaker that can adequately play back low
frequencies.
• Small : Use a small speaker that has inadequate playback capacity for
low frequencies.
• None : Select when the surround back speakers are not connected.
• 2spkrs : Use two surround back speakers.
• 1spkr : Use only one surround back speaker. When you select this
setting, connect the surround back speaker to the left (L) channel.
Even when the “S.Back“ setting is other than “None”, sound may
not be emitted from the surround back speaker, depending on the
playback source. In this case, make “Surround Parameter” – “S.Back”
setting other than “OFF” (vpage54).
NOTE
When the “Amp Assign” setting (vpage58) is other than “Normal”, you
cannot make the “S.Back” setting.
F.Height : Set the presence and size of the front height speakers.
• Large : Use a large speaker that can adequately play back low
frequencies.
• Small : Use a small speaker that has inadequate playback capacity for
low frequencies.
• None : Select when the front height speakers are not connected.
NOTE
When the “Amp Assign” setting (vpage58) is other than “Front Height”,
you cannot make the “F.Height” setting.
