Denon AVR 4308CI - AV Network Receiver - Page 36

- 36 -
EVENT PARAMETER
function example
Z2 PHONO MULTI ZONE-2 source change Z2PHONO<CR>
| ---The name of PARAMETER is |
IPOD
the same as that of the time of SI COMMAND.
Z2IPOD<CR>
SOURCE MULTI ZONE-2 mode cancel Z2SOURCE<CR>
** MULTI ZONE-2 VOLUME change , **:10 to 99 by ASCII Z280<CR>
98 = +18dB(MAX)
80 = 0dB
10 = -70dB
99 = ---(MIN)
ON MULTI ZONE-2 ON/OFF change Z2ON<CR>
OFF Z2OFF<CR>
Z2MU ON ZONE2 OUTPUT MUTE ON/OFF change Z2MUON<CR>
OFF Z2MUOFF<CR>
Z2CS ST
ZONE2 Channel setting
Z2CSST
MONO Z2CSMONO
Z2CV FL **
**:38 to 62 by ASCII , 50=0dB
Z2CVFL 50<CR>
FR **
**:38 to 62 by ASCII , 50=0dB
Z2CVFR 50<CR>
Z2HPF ON
ZONE2 HPF ON/OFF change
Z2HPFON<CR>
OFF Z2HPFOFF<CR>
Z2PS BAS **
ZONE2 BASS change
Z2PSBAS 00<CR>
TRE **
ZONE2 TEBLE change
Z2PSTRE 00<CR>
The PARAMETER of Z2 EVENT : Uses two ASCII characters. (see page4 J) section)
