Denon AVR-5308CI - Page 74

74
AVR-5308CI / AVC-A1HD
D10 NC O - Z O/L O/L NC
D11 FUNC CLK/XMDIT CLK O - Z O/L O/L FUNCTION SW control pin
D12 (FUNC STB C
) O - Z O/L O/L (FUNCTION SW control pin for AVPA1HD)
D13 NC O - Z O/L O/L NC
D14 MIC DET I Eu Z O/L O/L Microphone detect input (Detected : H)
D15 HOLD I/O - Z O/L O/L MAIN CPU access pin
D16 HLDA I/O - Z O/L O/L MAIN CPU access pin
E1 CPUD12 I/O - Z O/L O/L External memory access pin
E2 CPUD13 I/O - Z O/L O/L External memory access pin
E3 CPUD11 I/O - Z O/L O/L External memory access pin
E4 CPUD10 I/O - Z O/L O/L External memory access pin
E5 NC O - Z O/L O/L NC
E6 NC O - Z O/L O/L NC
E7 NC O - Z O/L O/L NC
E8 NC O - Z O/L O/L NC
E9 NC O - Z O/L O/L NC
E10 NC O - Z O/L O/L NC
E11 NC O - Z O/L O/L NC
E12 NC O - Z O/L O/L NC
E13 NC O - Z O/L O/L NC
E14 SIRIUS POWER O Ed Z O/L O/L Power control pin for SIRIUS
E15 CLKOUT I/O - Z O/L O/L MAIN CPU access pin
E16 RD I/O - Z O/L O/L MAIN CPU access pin
F1 CPUA13 I/O - Z O/L O/L External memory access pin
F2 CPUA14 I/O - Z O/L O/L External memory access pin
F3 RAMWR I/O - Z O/L O/L External memory access pin
F4 NC O - Z O/L O/L NC
F5 NC O - Z O/L O/L NC
F6 NC O - Z O/L O/L NC
F7 NC O - Z O/L O/L NC
F8 SW3.3V - - - - - +3.3V
F9 SW3.3V - - - - - +3.3V
F10 NC O - Z O/L O/L NC
F11 NC O - Z O/L O/L NC
F12 NC O - Z O/L O/L NC
F13 AUXRSV2 O - Z O/L O/L Not used
F14 AUXRSV1 O - Z O/L O/L Not used
F15 BHE I/O - Z O/L O/L MAIN CPU access pin
F16 WR I/O - Z O/L O/L MAIN CPU access pin
G1 CPUA11 I/O - Z O/L O/L External memory access pin
G2 CPUA12 I/O - Z O/L O/L External memory access pin
G3 CPUA5 I/O - Z O/L O/L External memory access pin
G4 NC O - Z O/L O/L NC
G5 NC O - Z O/L O/L NC
G6 NC O - Z O/L O/L NC
G7 GND - - - - - GND
G8 GND - - - - - GND
G9 GND - - - - - GND
G10 GND - - - - - GND
G11 NC O - Z O/L O/L NC
G12 NC O - Z O/L O/L NC
G13 NC O - Z O/L O/L NC
G14 AUXRSV3 O - Z O/L O/L Not used
G15 CS0 I/O - Z O/L O/L MAIN CPU access pin
G16 CS1 I/O - Z O/L O/L MAIN CPU access pin
H1 CPUD14 I/O - Z O/L O/L External memory access pin
H2 CPUA10 I/O - Z O/L O/L External memory access pin
H3 CPUA6 I/O - Z O/L O/L External memory access pin
H4 NC O - Z O/L O/L NC
H5 HD POWER O Ed Z O/L O/L HDRADIO POWER control pin
H6 SW3.3V - - - - - +3.3V
Pin Symbol I/O Op(Ext.) Res STBY stop Function
