PARTS LIST OF EXPLODED VIEW
Note:Thesymbolsinthecloumn"Remakes"indicatethefollowingdestinations..
JP:Japanmodel
E2:Europemodel
Ref.No. Part No. Part Name Remarks Q’TY
1 KNOB 5080211008000 1
2 KNOB 5087210998000 1
3 PANEL 3067211778000 1
4 WINDOW 5077211933000 1
5 INDICATOR 5160210123000 1
6 WINDOW 5070211953000 1
7 WINDOW 5070211943000 1
8 FELT 2690210089000 2
9 PLATE 4470210696000 1
10 BODY 3417210121000 1
11 BUTTON 5090212371000 1
12 INDICATOR 5160210113000 1
13 GUIDE 4350210001000 1
14 TER,RCA2PIN G601020163010 2
15 PLATE 4470210646000 1
16 GUIDE 4350210151000 1
17 PLATE 4470210686000 2
18 KNOB 5080211008000 1
19 SW,TACT G180000270010 1
20 LED,ROUND K500426000010 1
21 LED,ROUND K500056000060 1
22 KNOB 5080211008000 1
23 LED,ROUND K500052007010 1
24 CUSHION 4050211055000 2
25 SW,ENCODER G121121130010 1
26 SW,ENCODER G121161200020 1
27 FOOT 4000210271000 4
28 CHASSIS 3200211446000 1
29 CUSHION 4050211075000 4
30 SUPPORTER 4070001601010 5
31 SUPPORTER 4070210353000 1
32 GUIDE 4350210141000 1
33 HOLDER 4320210477000 6
34 HEATSINK 2120210668000 1
35 SHEET 1210210325000 2
36 CABINET 3000210476000 1
37 CUSHION 4050210275000 1
38 CHASSIS 3207211456000 1
39 STOPPER 4380040162010 1
40 CORD,AC L061001040010 1
41 FELT 2690040057010 2
42 MODULE E100151300010 1
43 MODULE E100151300020 1
44 TER,RCA4PIN G602405B0400Y 1
45 TER,RCA4PIN G602405BE1800 1
46 TER,RCA6PIN G603603B05000 2
47 TUNER,FM/AM E903018115010 1
47 TUNER,FM/AM E903141150010 1
48 TER,BOARDSCREW4P G612310584000 3
49 JACK,D6.5 G402042200000 1
50 JACK,DIN G403040020010 1
