Denon AVR-684 User Manual

21
ENGLISH
• After adjusting using the test tones, adjust the channel levels either according to the playback sources or to
suit your tastes, as (described) below.
1
Select the speaker whose level you want to
adjust.
2
The channel switches as shown below each
time the button is pressed.
(Remote control unit)
3
1, 2
3
Default setting of channel level is 0 dB.
The level of the selected speaker can be
adjusted within the range of +12 to –12 dB
using cursor buttons.
SW channel level can be turned off by
decreasing one step from -12 dB.
OFF ´ -12 dB ´ 12 dB
2
Select the Dolby Surround Pro Logic II mode.
(Main unit) (Remote control unit)
• The Dolby Pro Logic II indicator lights.
Display
Light
3
Play a program source with the
mark.
• For operating instructions, refer to the manuals
of the respective components.
Dolby Surround Pro Logic
II
mode
1
Select the function to which the component you
want to play is connected.
Example: DVD
5, 74, 61 2
4, 6
5, 7
1
8
5, 7
2
The Dolby Surround Pro
Logic
II Cinema or Music
mode can be chosen
directly by pressing the
CINEMA or MUSIC button
on the remote control unit
during playback in the
Dolby Surround Pro Logic
II mode.
(Main unit) (Remote control unit)
(Remote control unit)
FL CNTR FR SR SB
SW SL
NOTE:
• Please make sure the “AUDIO” position of
the slide switch on the remote control unit.
3
Adjust the level of the selected speaker.
(Remote control unit)
4
Select the surround parameter mode.
MODE cinema
Display
To perform this operation from the remote
control unit, check that the mode selector
switch is set to “AUDIO”.
(Main unit) (Remote control unit)
5
Select the optimum mode for the source.
(Main unit) (Remote control unit)
or or
MODE musicMODE cinemaMODE DOLBY PL
