Denon AVR-685 User Manual

40
AVR-1705/685
CPU P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC201 00D 963 0147 004 CXP740096-187Q
IC202 00D 963 0057 602 TDA7330BD for E2,E1C,EUT
IC271 00D 963 0114 707 MC7812CT for E2,E1C,EUT
IC272 00D 963 0114 600 MC7806CT for E3, AVR-685
IC273 00D 963 0147 703 KIA7906PI for E3, AVR-685
IC274 00D 963 0147 606 KIA78R09API for E3, AVR-685
IC301 00D 960 0180 004 LC75721E
IC302 00D 963 0074 504 BU2090F
Q201 00D 960 0285 006 KRC104S
Q202 00D 963 0121 509 KTC3875S
Q203,204 00D 963 0044 301 KTC2875B
Q205 00D 963 0120 704 KRA102S
Q251 00D 960 0097 207 KRA102M
Q252,253 00D 960 0196 603 KTC2874B
Q261 00D 963 0102 803 2SA933S for E2,E1C,EUT
Q262 00D 960 0111 808 KRC107S for E2,E1C,EUT
Q310,312,314 00D 963 0120 704 KRA102S
Q311,313,315 00D 963 0120 801 KRC102S
D201 00D 960 0197 000 KDS160
D202 00D 963 0058 407 1N4007
D203 00D 963 0020 309 1SS133
D204,205 00D 960 0197 000 KDS160
D206 00D 963 0020 309 1SS133 for E2,E1C,EUT
D209,210 00D 963 0020 309 1SS133 for E3, AVR-685
D251 00D 963 0058 407 1N4007
D302-304 00D 963 0058 407 1SS133
D305 00D 960 0197 000 KDS160
D308,309 00D 960 0197 000 KDS160
ZD201 00D 963 0047 502 MTZJ3.3B
ZD301 00D 960 0095 801 MTZJ6.8B
ZD331 00D 960 0095 500 MTZJ5.1B
ZD332 00D 960 0095 500 MTZJ5.1B
ZD335,336 00D 960 0095 500 MTZJ5.1B
LED301-304 00D 960 0197 204 LED,PI5-RD/HL50RDRF4T
LED306 00D 960 0197 204 LED,PI5-RD/HL50RDRF4T
LED308-310 00D 960 0197 204 LED,PI5-RD/HL50RDRF4T
FL301 00D 963 0109 505 DISPLAY,FLT 16-ST-66GNK
RESISTORS GROUP
R271 00D 963 0047 900 R,METAL 4.7-J,1W for E2,E1C,EUT
R272 00D 963 0047 900 R,METAL 4.7-J,1W for E3, AVR-685
CAPACITORS GROUP
C201 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V
C202 00D 963 9004 711 C,CERAMIC 0.1UF-Z/50V
