AVR-1705/685

! 40 00D 963 0141 602 POWER TRANS for E3, AVR-685 1

! 40 00D 963 0109 615 POWER TRANS for E2 1

! 40 00D 963 0109 628 POWER TRANS for E1C 1

! 40 00D 963 0109 602 POWER TRANS for EUT 1

41 - HEAT SINK REG TR(24X60) 2

42 - HEAT SINK REG TR(46X70) 1

44 00D 960 0184 000 BRACKET SCREW 4

46 00D 963 0119 906 TER, BOARD SCREW 8P 2

! 48 00D 960 0181 508 SOCKET, POWER RECEPTA(120V) for E3,EUT, AVR-685 1

! 48 00D 960 0143 203 SOCKET, POWER RECEPTA(220V) for E2 1

49 00D 960 0192 403 STOPPER CORD 1

! 50 00D 963 0098 603 AC CORD for E3, AVR-685 1

! 50 00D 963 0109 806 AC CORD for E2 1

! 50 00D 963 0109 806 AC CORD for E1C 1

! 50 00D 963 0149 002 AC CORD for EUT 1

51 00D 963 0137 205 CHASSIS MAIN 1

52 00D 963 0137 904 FOOT 4

53 00D 960 0235 205 CUSHION FOOT 4

54 00D 963 0072 302 CUSHION RUBBER 2

55 00D 963 0051 103 SPACER CARD 2

56 00D 960 0003 301 SUPPORTER PCB 2

57 00D 960 0184 107 BRACKET SUPPORTER 1

58 00D 963 0044 602 SUPPORTER PC 1

67 00D 963 0094 102 PLATE INPUT 1

68 00D 963 0094 005 CUSHION INPUT 1

70 00D 963 0145 608 TUNER PACK for E3, AVR-685 1

70 00D 963 0145 705 TUNER PACK for E2,E1C,EUT 1

71 00D 963 0137 302 CHASSIS BACK for E3 1

71 00D 963 0137 603 CHASSIS BACK for E2 1

71 00D 963 0137 700 CHASSIS BACK for E1C 1

71 00D 963 0137 506 CHASSIS BACK for EUT 1

71 00D 963 0137 409 CHASSIS BACK for AVR-685 1

72 - SHEET CABINET 3

73 00D 963 0120 306 BRACKET SIDE for E2,E1C,EUT 1

74 - HEAT SINK TR(15X30) for E2,E1C,EUT 1

75 - TAPE ACETATE 1

★ 76

00D 963 0140 302 SERIAL NO. LABEL 1

★ 77

00D 963 0140 409 DOLBY/DTS:RATING LABEL 1

★ 78

00D 963 0140 506 RATING LABEL for EUT 1

SCREWS

A 00D 963 0018 007 SCREW,(3X8 ZNY/BH) 64

B 00D 963 0136 701 SCREW,(3X8 WASHER PI12) for E3 4

B 00D 963 0136 604 SCREW,(3X8 WASHER PI12) for E2,E1C,EUT, AVR-685 4

C 00D 963 0018 104 SCREW,(3X17 ZNY/BH) 2

D 00D 963 0108 714 SCREW,(3X10 BK/BH DOT) 35

E 00D 963 9006 175 SCREW,(3X14 P+S WASHER ZNY/BH) 18

F 00D 963 0018 104 SCREW,(3X17 ZNY/BH) 1

G 00D 963 0048 307 SCREW,(4X8 BK/BH DOT) for E3 6

G 00D 963 9004 012 SCREW,(4X8 NI/BH DOT) for E2,E1C,EUT, AVR-685 6

H 00D 960 9008 417 SCREW,(4X8 P+S WASHER ZNY/BH) 4

I 00D 963 0136 604 SCREW,(3X8 WASHER PI12) 1

J 00D 963 9004 025 SCREW,(4X6 ZNY/BH) 6

K 00D 963 9004 041 SCREW,(3X5 ZNY/BH) for E2,E1C,EUT 2

L 00D 963 0136 507 SCREW,(3X8 WASHER PI9.5 ZNY/BH) 2
