Denon AVR-785 User Manual

42
AVR-1905/785 AVC-1590
CPU/FRONT P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC201 00D 963 0182 904 CXP740010-192Q J020740010192 *
IC202 00D 963 0057 602 TDA7330BD For E2,EK,G2A J080733000010
IC271 00D 963 0147 606 KIA78R09API For E3,EU J126780900120
IC272 00D 963 0114 600 MC7806CT J126780600160
IC273 00D 963 0147 703 KIA7906PI For E3,EU J126790600030
IC301 00D 960 0180 004 LC75721E J127757210010
IC302 00D 963 0074 504 BU2090F J044209000010
IC391 00D 963 0113 009 MODULE GP1FA513RZ For E3,EU,E2,EK,G2A,G1C,G1K,GUT E100151300020
Q201 00D 960 0285 006 KRC104S J522104S00210
Q202 00D 963 0121 509 KTC3875S J522038750210
Q251 00D 960 0097 207 KRA102M J6002202M0010
Q252 00D 960 0196 603 KTC2874B J502287400010
Q253 00D 960 0196 603 KTC2874B J502287400010
Q254 00D 963 0120 801 KRA102S J520010200210
Q255 00D 963 0044 301 KTC2875B J5222875B0010
Q256 00D 963 0044 301 KTC2875B J5222875B0010
Q257 00D 963 0120 801 KRA102S J520010200210
Q258 00D 963 0044 301 KTC2875B J5222875B0010
Q259 00D 963 0044 301 KTC2875B J5222875B0010
Q261 00D 963 0102 803 2SA933S For E2,EK,G2A J5000933S0050
Q262 00D 960 0111 808 KRC107S For E2,EK,G2A J5020107S0050
Q310 00D 963 0120 801 KRA102S J520010200210
Q311 00D 963 0120 801 KRC102S J522010200210
Q312 00D 963 0120 801 KRA102S J520010200210
Q313 00D 963 0120 801 KRC102S J522010200210
Q314 00D 963 0120 801 KRA102S J520010200210
Q315 00D 963 0120 801 KRC102S J522010200210
Q316 00D 963 0120 801 KRA104S J520010400210
D201 00D 963 0096 605 1N4148WS K005041480010
D202 00D 963 0058 407 1N4007 K000400700520
D203 00D 963 0020 309 1SS134T K000013300520
D204 00D 963 0096 605 1N4148WS K005041480010
D205 00D 963 0096 605 1N4148WS K005041480010
D206 00D 963 0020 309 1SS136T For E2,EK,G2A K000013300520
D212 00D 963 0020 309 1SS134T K000013300520
D222 00D 963 0020 309 1SS135T For E3,EU K000013300520
D302 00D 963 0020 309 1SS133T K000013300520
D303 00D 963 0020 309 1SS133T K000013300520
D304 00D 963 0020 309 1SS133T K000013300520
D305 00D 960 0197 000 KDS160 K005016000010
D308 00D 960 0197 000 KDS160 K005016000010
D309 00D 960 0197 000 KDS160 K005016000010
ZD201 00D 963 0047 502 MTZJ3.3B K06003R344520
ZD301 00D 960 0095 801 MTZJ6.8B K06006R844520
ZD331 00D 960 0095 500 MTZJ5.1B K06005R144520
ZD332 00D 960 0095 500 MTZJ5.1B K06005R144520
ZD335 00D 960 0095 500 MTZJ5.1B K06005R144520
ZD336 00D 960 0095 500 MTZJ5.1B K06005R144520
LED301 00D 960 0197 204 LED, PI5-RD/HL50RDRF4T K500052015010
LED302 00D 960 0197 204 LED, PI5-RD/HL50RDRF4T K500052015010
LED303 00D 960 0197 204 LED, PI5-RD/HL50RDRF4T K500052015010
LED304 00D 960 0197 204 LED, PI5-RD/HL50RDRF4T K500052015010
LED305 00D 960 0197 204 LED, PI5-RD/HL50RDRF4T For JP K500052015010
LED306 00D 960 0197 204 LED, PI5-RD/HL50RDRF4T K500052015010
LED307 00D 960 0197 204 LED, PI5-RD/HL50RDRF4T K500052015010
LED308 00D 960 0197 204 LED, PI5-RD/HL50RDRF4T K500052015010
LED309 00D 960 0197 204 LED, PI5-RD/HL50RDRF4T K500052015010
LED310 00D 960 0197 204 LED, PI5-RD/HL50RDRF4T K500052015010
FL301 00D 963 0109 505 DISPLAY,FLT 16-ST-66GNK K530166600010
CAPACITORS GROUP
C201 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160
C202 00D 963 9004 711 C,CERAMIC 0.1UF-Z/50V D011104597160
C203 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160
C204 00D 963 9006 476 CAP.E. 4.7UF/50V N211247978110
C205 00D 963 9004 711 C,CERAMIC 0.1UF-Z/50V D011104597160
C206 00D 963 9006 434 CAP.E. 47UF/16V For E2,EK,G2A N211247038110
C207 00D 963 9004 533 C,CERAMIC 0.01UF-M/16V For E2,EK,G2A D005103773530
C208 00D 963 9004 614 C,CERAMIC 270PF-J/50V For E2,EK,G2A D010271167160
C209 00D 963 9006 308 CAP.E. 10UF/50V For E2,EK,G2A N211210078110
C210 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V For E2,EK,G2A D011103777160
C211 00D 963 9004 614 C,CERAMIC 27PF-J/50V For E2,EK,G2A D010270167160
