Denon AVR-785 - PARTS LIST OF EXPLODED VIEW

65
AVR-1905/785 AVC-1590
PARTS LIST OF EXPLODED VIEW
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model EU : U.S.A. model (AVR-785)
E2 : Europe model EK : U.K. model E2A : Asia model E1C : China model EUT : Taiwan R.O.C. model
E1K : Korea model JP : Japan model
Ref. No. Part No. Part Name Remarks Q'ty New
00D 963 0186 900 MAIN PWB ASS'Y 7025HK0319010 For KE3,SRE3 *
00D 963 0187 006 MAIN PWB ASS'Y 7025HK0319030 For KE2,SE2,G2A *
00D 963 0187 103 MAIN PWB ASS'Y 7025HK0319050 For KEK,SEK *
00D 963 0187 200 MAIN PWB ASS'Y 7025HK0319090 For G1C *
00D 963 0187 307 MAIN PWB ASS'Y 7025HK0319080 For G1K *
00D 963 0187 404 MAIN PWB ASS'Y 7025HK0319070 For GUT *
00D 963 0157 007 MAIN PWB ASS'Y 7025HK0320100 For JP *
60 - MAIN PCB ASSY 7028063121010 For KE3,SRE3
60 - MAIN PCB ASSY 7028063121030 For KE2,SE2,G2A
60 - MAIN PCB ASSY 7028063121050 For KEK,SEK
60 - MAIN PCB ASSY 7028063121070 For GUT
60 - MAIN PCB ASSY 7028063121080 For G1K
60 - MAIN PCB ASSY 7028063121090 For G1C
60 - MAIN PCB ASSY 70280631210A0 For JP
53 - HEAD PHONE PCB ASSY 7028063123010
54 - ENCODER PCB ASSY 7028063122010
00D 963 0187 501 CPU/FRONT PWB ASS'Y 7025HK0319011 For KE3,SRE3 *
00D 963 0187 608 CPU/FRONT PWB ASS'Y 7025HK0319031 For KE2,SE2,G2A,KEK,SEK *
00D 963 0187 705 CPU/FRONT PWB ASS'Y 7025HK0319081 For G1K,G1C,GUT *
00D 963 0157 104 CPU/FRONT PWB ASS'Y 7025HK0320101 For JP *
57 - FRONT PCB ASSY 7028063131010
For KE3,KE2,SE2,G2A,G1K,KEK,SEK,G1C,GUT,SRE3
57 - FRONT PCB ASSY 70280631310A0 For JP
62 - CPU PCB ASSY 7028063132010 For KE3,SRE3
62 - CPU PCB ASSY 7028063132030 For KE2,SE2,G2A,KEK,SEK
62 - CPU PCB ASSY 7028063132070 For G1K,G1C,GUT
62 - CPU PCB ASSY 70280631320A0 For JP
56 - OPTICAL-IN PCB ASSY 7028063133010
For KE3,KE2,SE2,G2A,G1K,KEK,SEK,G1C,GUT,SRE3
52 - POWER-SW PCB ASSY 7028063134010
00D 963 0187 802 CNT PWB ASS'Y 7025HK0319012 For KE3,SRE3 *
00D 963 0187 909 CNT PWB ASS'Y 7025HK0319032 For KE2,SE2,G2A *
00D 963 0188 005 CNT PWB ASS'Y 7025HK0319052 For KEK,SEK,G1C *
00D 963 0188 102 CNT PWB ASS'Y 7025HK0319082 For G1K *
00D 963 0188 209 CNT PWB ASS'Y 7025HK0319072 For GUT *
00D 963 0188 306 CNT PWB ASS'Y 7025HK0320102 For JP *
61 - CNT PCB ASSY 7028063141010
58 - 2CH-AMP PCB ASSY 7028063142010
59 - PRE-AMP PCB ASSY 7028063143010
70 - OUTLET PCB ASSY 7028063144010 For KE3,GUT,SRE3
70 - OUTLET PCB ASSY 70280631440A0 For JP
70 - OUTLET PCB ASSY 7028063145030 For KE2,SE2,G2A
70 - OUTLET PCB ASSY 7028063145080 For G1K
63 - EXT-IN PCB ASSY 7028063141030
For KE2,SE2,G2A,G1K,KEK,SEK,G1C,GUT
63 - EXT-IN PCB ASSY 70280631510A0 For JP
00D 963 0188 403 INPUT-VOL-E3 PWB ASS'Y 7025HK0319016 For KE3,SRE3 *
64 - INPUT-VOL PCB ASSY 7028063181010 For KE3,SRE3
66 - S-C VIDEO PCB ASSY 7028063182010 For KE3,SRE3
00D 963 0188 500 INPUT-VOL PWB ASS'Y 7025HK0319057 For KE2,SE2,G2A,KEK,SEK,G1C *
00D 963 0188 607 INPUT-VOL PWB ASS'Y 7025HK0319087 For G1K,GUT *
00D 963 0188 704 INPUT-VOL PWB ASS'Y 7025HK0320103 For JP *
64 - INPUT-VOL PCB ASSY 7028063191010
For KE2,SE2,G2A,G1K,KEK,SEK,G1C,GUT
64 - INPUT-VOL PCB ASSY 7028063191080 For JP
66 - S-C VIDEO PCB ASSY 7028063192010 For KE2,SE2,G2A,KEK,SEK,G1C
66 - S-C VIDEO PCB ASSY 7028063192050 For G1K,GUT,JP
