AVR-1905/785 AVC-1590
DSP P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC802 00D 963 0113 009 MODULE GP1FA513RZ E100151300020
IC803 00D 963 0113 009 MODULE GP1FA513RZ E100151300020
IC804 00D 963 0147 402 ADSP-21266 J080212660010
IC805 00D 963 0146 908 LH28F800BJE J002288000010
IC807 00D 963 0096 100 LC89057W J046890570010
IC808 00D 963 0158 802 AD1837AAS J080183700020
IC809 00D 960 0266 805 MM74LCX244 J040742440180
IC810 00D 960 0266 805 MM74LCX244 J040742440180
IC811 00D 960 0266 805 MM74LCX244 J040742440180
IC812 00D 960 0266 902 MM74HCT244 J040742440190
IC814 00D 963 0102 308 MM74HC00MTCX J040740000190
IC815 00D 963 0102 308 MM74HC00MTCX J040740000190
IC815A 00D 963 0043 807 BA4510F J121451000010
IC816 00D 963 0147 208 74LVX157 J040741570100
IC816A 00D 963 0043 807 BA4510F J121451000010
IC817A 00D 963 0024 004 NJM2068M J121206800020
IC818 00D 963 0147 305 SN74LV573APW J040745730200
IC818A 00D 963 0024 004 NJM2068M J121206800020
IC819 00D 963 0147 305 SN74LV573APW J040745730200
IC819A 00D 963 0024 004 NJM2068M J121206800020
IC820 00D 963 0147 101 SN74LVC139A J040741390040
IC820A 00D 963 0024 004 NJM2068M J121206800020
IC821 00D 963 0096 003 74LCX74MTC J040747400190
IC822 00D 960 0159 501 KIA7805API J126780500110
IC823 00D 963 0111 603 RC1117-3.3 J126111733020
IC824 00D 963 0183 602 RC1117-1.2 J126111712010 *
IC825 00D 963 0096 003 74LCX74MTC J040747400190
IC826 00D 963 0113 009 MODULE GP1FA513TZ E100151300010
IC827 00D 963 0146 801 IC63LV1024-10T J001711240010
Q804C 00D 960 0196 603 KTC2874B J502287400010
Q804FL 00D 960 0196 603 KTC2874B J502287400010
Q804FR 00D 960 0196 603 KTC2874B J502287400010
Q804SBL 00D 960 0196 603 KTC2874B J502287400010
Q804SBR 00D 960 0196 603 KTC2874B J502287400010
Q804SL 00D 960 0196 603 KTC2874B J502287400010
Q804SR 00D 960 0196 603 KTC2874B J502287400010
Q804SW 00D 960 0196 603 KTC2874B J502287400010
Q808 00D 963 0120 801 KRC102S J522010200210
Q809 00D 963 0120 801 KRA102S J520010200210
D801 00D 960 0197 000 KDS160 K005016000010
D803 00D 960 0197 000 KDS160 K005016000010
RESISTORS GROUP
R831 00D 963 0120 908 COIL,BEAD 121JT D340160800050
R832 00D 963 0120 908 COIL,BEAD 121JT D340160800050
R833 00D 963 0120 908 COIL,BEAD 121JT D340160800050
CAPACITORS GROUP
C801 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160
C802 00D 963 9006 528 C,CERAMIC 22PF-J/50V D010220167160
C803 00D 963 9006 528 C,CERAMIC 22PF-J/50V D010220167160
C805 00D 963 9006 528 C,CERAMIC 22PF-J/50V D010220167160
C807 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160
C808 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080
C809 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160
C810 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080
C811 00D 963 9006 528 C,CERAMIC 22PF-J/50V D010220167160
C812 00D 963 9005 927 C,ELECT 0.1UF-M/50V D040R10087070
C813 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160
C814 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080
C815 00D 963 9005 312 C,ELECT 100UF-M/10V D040101082060
C816 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160
C817 00D 963 9005 778 C,ELECT 10UF-M/50V D040100087050
C818 00D 963 9005 749 C,ELECT 1UF-M/50V D040010087080
C819 00D 963 9005 901 C,ELECT 470UF-M/10V D040471082060
C821 00D 963 9005 901 C,ELECT 470UF-M/10V D040471082060
C830 00D 963 9005 901 C,ELECT 470UF-M/10V D040471082060
C831 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160
C832 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160
C833 00D 963 9005 367 C,CERAMIC 0.015UF-K/50V D011153777160
C834 00D 963 9005 367 C,CERAMIC 0.015UF-K/50V D011153777160
C835 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160
C836 00D 963 9004 685 C,CERAMIC 1000PF-K/50V D011102777160
