63
AVR-1905/785 AVC-1590
D-VIDEO/PRE-OUT P.W.B. UNIT ASS'Y (for AVC-1590 Japan model only)
Ref. No. Part No. Part Name Remarks No. Q'ty New
SEMICONDUCTORS GROUP
IC651 00D 960 0175 200 BA7625 J171762500000
IC652 00D 963 0083 304 BA7626 J171762600000
IC653 00D 963 0083 304 BA7626 J171762600000
IC654 00D 963 0068 002 BU4052BCF J040405200060
IC655 00D 963 0068 002 BU4052BCF J040405200060
Q651 00D 960 0005 105 KTA1266Y J5001266Y0050
Q652 00D 960 0005 105 KTA1266Y J5001266Y0050
Q653 00D 960 0005 105 KTA1266Y J5001266Y0050
CAPACITORS GROUP
C651 00D 963 9006 476 CAP.E. 4.7UF/50V N211247978110
C652 00D 963 9006 476 CAP.E. 4.7UF/50V N211247978110
C653 00D 963 9006 476 CAP.E. 4.7UF/50V N211247978110
C654 00D 963 9006 476 CAP.E. 4.7UF/50V N211247978110
C655 00D 963 9006 476 CAP.E. 4.7UF/50V N211247978110
C656 00D 963 9006 476 CAP.E. 4.7UF/50V N211247978110
C657 00D 963 9005 969 C,ELECT 4700UF-M/6.3V D040472081000
C658 00D 963 9006 463 CAP.E. 470UF/6.3V N211247118110
C659 00D 963 9006 463 CAP.E. 470UF/6.3V N211247118110
C660 00D 963 9005 312 C,ELECT 100UF-M/10V D040101082060
C661 00D 963 9005 312 C,ELECT 100UF-M/10V D040101082060
C662 00D 963 9005 312 C,ELECT 100UF-M/10V D040101082060
C665 00D 963 9006 476 CAP.E. 4.7UF/50V N211247978110
C666 00D 963 9006 476 CAP.E. 4.7UF/50V N211247978110
C667 00D 963 9006 476 CAP.E. 4.7UF/50V N211247978110
C671 00D 963 9006 379 CAP.E. 1UF/50V N211210978110
C672 00D 963 9006 379 CAP.E. 1UF/50V N211210978110
C673 00D 960 9009 856 C,CERAMIC 0.022UF-Z/50V D011223597160
C674 00D 963 9005 312 C,ELECT 100UF-M/10V D040101082060
C677 00D 963 9004 520 C,CERAMIC 100PF-K/50V D005101177520
C678 00D 963 9004 520 C,CERAMIC 100PF-K/50V D005101177520
C679 00D 963 9004 520 C,CERAMIC 100PF-K/50V D005101177520
C681 00D 963 9006 379 CAP.E. 1UF/50V N211210978110
C682 00D 963 9006 379 CAP.E. 1UF/50V N211210978110
C687 00D 963 9004 520 C,CERAMIC 100PF-K/50V D005101177520
C688 00D 963 9004 520 C,CERAMIC 100PF-K/50V D005101177520
C689 00D 963 9004 520 C,CERAMIC 100PF-K/50V D005101177520
C690 00D 963 9004 520 C,CERAMIC 100PF-K/50V D005101177520
C691 00D 963 9006 379 CAP.E. 1UF/50V N211210978110
C692 00D 963 9006 379 CAP.E. 1UF/50V N211210978110
C695 00D 963 9004 520 C,CERAMIC 100PF-K/50V D005101177520
C696 00D 963 9004 520 C,CERAMIC 100PF-K/50V D005101177520
C697 00D 963 9004 520 C,CERAMIC 100PF-K/50V D005101177520
C698 00D 963 9004 520 C,CERAMIC 100PF-K/50V D005101177520
C699 00D 963 9004 520 C,CERAMIC 100PF-K/50V D005101177520
C788 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160
C788C 00D 963 9006 515 C,CERAMIC 100PF-J/50V- D010101167160
C788FL 00D 963 9006 515 C,CERAMIC 100PF-J/50V- D010101167160
C788FR 00D 963 9006 515 C,CERAMIC 100PF-J/50V- D010101167160
C788SBL 00D 963 9006 515 C,CERAMIC 100PF-J/50V- D010101167160
C788SBR 00D 963 9006 515 C,CERAMIC 100PF-J/50V- D010101167160
C788SL 00D 963 9006 515 C,CERAMIC 100PF-J/50V- D010101167160
C788SR 00D 963 9006 515 C,CERAMIC 100PF-J/50V- D010101167160
C788SW 00D 963 9006 515 C,CERAMIC 100PF-J/50V- D010101167160
C789 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160
OTHER PARTS GROUP
CN512 00D 963 0085 603 CN.WAFER 5P L101100030510
CN654 00D 963 0097 206 CN.WAFER 8P L101100030810
CN659 00D 963 0097 206 CN.WAFER 8P L101100030810
CN902 00D 963 0184 300 CN,WIRE 150MM/14P L000151140030 *
CP512 00D 963 0086 903 CN.WAFER 5P L101100040510
CP603 00D 963 0097 400 CN.WAFER 8P L101100040810
CP654 00D 963 0097 400 CN.WAFER 8P L101100040810
CP659 00D 963 0097 400 CN.WAFER 8P L101100040810
JACK601D 00D 963 0085 108 CN.SOCKET 14P L170001200010
JACK602D 00D 963 0085 108 CN.SOCKET 14P L170001200010
JACK603D 00D 963 0085 108 CN.SOCKET 14P L170001200010
JACK604D 00D 963 0085 108 CN.SOCKET 14P L170001200010
JACK666P 00D 963 0132 103 TER,RCA 4PIN G602405B0400Y
JACK667P 00D 963 0132 103 TER,RCA 4PIN G602405B0400Y
