Denon AVR-787 - Rear Panel; Remote Control Unit

Getting Started Getting Started
5
ENGLISH
ENGLISH
Remote control unit
Remote control signal
transmitter························(3)
Power buttons················(10)
Master volume control
buttons····························(21)
CH SELECT/ENTER
button························(11, 32)
NIGHT/AUDIO
button························(36, 59)
MUTING button··············(22)
STATUS/RETURN
button························(22, 59)
Tuner system/System
buttons······················(33, 59)
Rear panel
q
EXT. IN terminals·······································(15)
w
DIGITAL terminals
(Optical/Coaxial) ·······································(9, 16)
e
AUDIO OUT terminals·······························(14)
r
Speaker terminals ·······································(8)
t
Power supply cord·····································(20)
y
AC outlets···················································(20)
u
PRE OUT terminals······························(19, 20)
i
COMPONENT VIDEO terminals··················(9)
o
VIDEO/S-VIDEO terminals··························(9)
!0
DOCK CONTROL jack································(18)
!1
AUDIO IN terminals·····································(9)
!2
XM terminal ···············································(18)
!3
ANTENNA terminals ·································(17)
!4
REMOTE CONTROL jacks ·························(19)
VIDEO SELECT/SETUP
button························(36, 59)
Function buttons············(21)
Indicator··························(58)
Cursor buttons
(
DD
,
HH
,
FF
,
GG
) ····················(11)
ON SCREEN/
DISPLAY button········(22, 59)
DIMMER/MENU
button························(22, 59)
Mode selector
switches····················(10, 58)
System buttons ·····(59 ~ 61)
!2!3 !1 !0 o i u y t
w e r
q
!4
[ Front ]
NOTE:
• If buttons on the front or rear are pressed strongly, the button on the opposite side will be activated
too.
