Denon AVR-983 Service Manual

50
50
AVR-2803/983/AVC-2870
JK404 205 0902 004 1P S-TERMINAL(SW)
JK406-408 204 8654 005 3P PIN JACK (S2GND)
JK701,702 204 8260 004 MINI JACK
JK703 204 8649 007 MINI JACK (RD)
JK704 204 8657 002 MINI JACK
L451 235 0060 963 INDUCTOR(150)ST
RL401-404 214 0223 004 RELAY(EC2-24N35)
S201 212 0373 000 ROT.ENCODER-EC16B
S202-205 212 5611 903 TACT SWITCH(TAPE H5)
S401 212 0408 001 SLIDE SWITCH for E1,E1H
TP601 205 0154 030 3P NH CONNECTOR BASE
W701,702 205 1034 007 M3 SCREW TERMINAL
W708,709 205 1034 010 M3 SCREW TERMINAL
X451 399 0739 006 X'TAL(14.32M-RIBER)
X452 399 0105 009 CSB503F2
Ref.No. Part No. Part Name Remarks New

Denon AVR-983 Specifications

General

Brand	Denon
Model	AVR-983
Category	Stereo Receiver
Language	English
