Denon AVR-983 Service Manual

66
66
AVR-2803/983/AVC-2870
CX134 205 1091 037 13P CON BASE TWG-P
JK501 205 1250 001 8P SP TERMINAL(V0)
JK502 205 1252 009 4P SP TERMINAL(V0)
JK503 205 1251 000 6P SP TERMINAL(V0)
JK504 204 8217 031 H/P JACK (BK(AU))
JK801,802 204 8540 009 4P PIN JACK
L101,102 235 0068 004 INDUCTOR(1MH)
L201 235 0068 004 INDUCTOR(1MH)
L301,302 235 0068 004 INDUCTOR(1MH)
L401,402 235 0068 004 INDUCTOR(1MH)
RL101 214 0217 007 RELAY(DS24D2)
RL201 214 0217 007 RELAY(DS24D2)
RL301,302 214 0217 007 RELAY(DS24D2)
RL401 214 0217 007 RELAY(DS24D2)
RL501 214 0223 004 RELAY(EC2-24N35)
S501 212 0420 005 1P PUSH SW(NON LOCK)
! T501 233 0644 008 MINI TRANS(383-N)
TP101 205 0190 065 6P NH CONNECTOR BASE
TP301 205 0190 081 8P NH CONNECTOR BASE
W301 203 0461 002 1P SIN CON.ASS'Y
W501 203 0459 014 1P SIN CON. ASS'Y
W502 203 0475 056 1P CONTACT ASS
W716 203 0440 010 1P CONTACT ASS'Y
Ref.No. Part No. Part Name Remarks New
