87
87
AVR-2803/983/AVC-2870
47 MICA SHEET 14
48 274 0196 010 MN15N LF551 TR101,102,201,301,302,401,402 7
49 272 0157 011 MP15P LF551 TR103,104,203,303,304,403,404 7
50 412 4127 001 PWB BRACKET (B) 2
51 412 4995 000 RADIATOR BRACKET (F) 1
52 412 4995 013 RADIATOR BRACKET (R) 1
53 412 4296 107 RADIATOR BRACKET 1
! 54 233 6443 009 POWER TRANS(283E3) for EU,EC,EUT 1 *
! 54 233 6447 005 POWER TRANS(283E2) for E2 1 *
! 54 233 6448 004 POWER TRANS(283E1) for E1,E1H 1 *
! 54 233 6449 003 POWER TRANS(283-220V for E1C,E1K 1 *
! 54 233 0657 008 POWER TRANS(283-N) for JP 1 *
58 112 0844 006 KNOB (M) ASS'Y for black model 1
58 112 0844 019 KNOB (M) ASS'Y for gold model 1
59 112 0846 004 KNOB (F) ASS'Y for black model 1
59 112 0846 017 KNOB (F) ASS'Y for gold model 1
60 112 0848 002 KNOB (S) ASS'Y for black model 1
60 112 0848 015 KNOB (S) ASS'Y for gold model 1
61 113 1873 105 PUSH KNOB for black model 1
61 113 1873 118 PUSH KNOB for gold model 1
62 513 3858 001 FUSE CAUTION LABEL for EU,EC 1
66 GEN6071H5 RATING LABEL (T) for EUT 1 *
66 GEN6126-5 RATING LABEL (KOREA) for E1K 1 *
67 513 3745 004 EMI LABEL (KOREA) for E1K 1
68 102 0638 008 TOP COVER for black model 1
68 102 0638 011 TOP COVER for gold model 1
73 461 1017 035 RUBBER SHEET for JP 2
74 415 0845 001 SP RIVET for E2,E1,E1C,E1H,E1K 18
75 515 8030 066 PRESET LABEL for E1,E1H 1
76 513 3214 108 NOTICE SHEET for JP 1
77 GEN6139H LICENSE SUB ASS'Y for EU,EC,E2,E1,E1C,E1H,EUT,E1K 1
77 GEN6179 LICENSE SUB ASS'Y for JP 1
78 203 5177 045 3P VH CON.CORD for JP 1
79 513 1581 011 SERIAL NO. SHEET for EU,EC,E2,E1,E1C,E1H,EUT,JP 1
80 204 2546 038 8P KR-KR RIBBON 100 for EU,EC,E2,E1,E1C,E1H,EUT,E1K 1
80 204 2954 002 10P-8P PH CON.CORD for JP 1
SCRWS
101 471 8010 100 SPECIAL SCREW 1
102 473 7002 005 3X6 CBTS(S)-Z 12
103 473 7002 018 3X8 CBTS (S)-Z for EU,EC,EUT 17
103 473 7002 018 3X8 CBTS (S)-Z for E2,E1,E1C,E1H,E1K 19
104 473 7003 017 3X8 CFTS (S)-B for JP 2
105 473 7004 016 4X6 CBTS (S)-Z 4
106 473 7015 018 3X8 CBTS (S)-B for EU,EC,EUT 15
106 473 7015 018 3X8 CBTS (S)-B for E2,E1,E1C,E1H,E1K 16
106 473 7015 018 3X8 CBTS (S)-B for JP 12
107 473 7500 015 3X8 CBTS (P)-Z 16
108 473 7500 028 3X8 CFTS (P)-Z 6
109 473 7501 001 3X10 CBTS (P)-Z 3
110 473 7501 030 3X20 CBTS (P)-Z 3
111 473 8034 056 3X14 CBTS(B)Z 8
112 473 8034 098 3X10 CBTS(B)-B for EU,EC,E2,E1,E1H,EUT,E1K 4
112 473 8034 098 3X10 CBTS(B)-B for JP 10
113 473 8064 000 4X8 CBTS(B)-B-3P for black model 6
113 473 8064 013 4X8 CBTS(B)-N-3P for gold model 6
114 475 6124 003 12 NUT 1
115 477 0064 107 FIXING SCREW for EU,EC,E1,E1H,EUT 47
115 477 0064 107 FIXING SCREW for E2,E1C,E1K 45
115 477 0064 107 FIXING SCREW for JP 40
116 477 0153 018 3X16 CPTS(B) SW W 14
Ref.No. Part No. Part Name Remarks Q'ty New
To Next Page
