Manual Setup
Perform when setting the speakers manually or when changing settings
made in Audyssey
®
Setup.
0
If you add or remove a speaker after performing Audyssey
®
Setup, you
will no longer be able to select Audyssey MultEQ
®
XT32, Audyssey
Dynamic EQ
®
or Audyssey Dynamic Volume
®
. (v p. 196)
0
“Manual Setup” can be used without changing the settings. Please set if
necessary.
Amp Assign
Select the power amplifier usage method to match your speaker system.
o
Assign Mode
Select how to use the power amp.
You need to configure the detailed settings for the speaker
configuration in accordance with the selected mode. Select Assign
Mode configure the corresponding detailed settings.
13.1ch:
0
Settings to assign all power amplifier
within this unit to MAIN ZONE to play
back up to 13.1-channels.
0
You can connect speakers for up to 15.1-
channels for MAIN ZONE.
The speaker output automatically switches
for playing back up to 13.1-channels in
accordance with the input signal and sound
mode when 15.1-channel speakers are
installed.
11.1ch + ZONE2
(Default):
0
Setting to assign the power amplifiers in
this unit for ZONE2 to 2-channels.
0
You can connect speakers for up to 11.1-
channels for MAIN ZONE.
Contents Connections Playback Settings Tips Appendix
232
Front panel Display Rear panel Remote Index

Denon AVR-A1H Specifications

General

Channels	15.4
Power Output	150 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
HDMI Inputs	7
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
Auro-3D	Yes
HEOS Built-in	Yes
Wi-Fi	Yes
Bluetooth	Yes
Weight	70.5 lbs
HDCP Support	HDCP 2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
Wireless Audio	AirPlay 2, Bluetooth, HEOS
Phono Input	Yes
Frequency Response	10 Hz - 100 kHz
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Inputs	7 HDMI, 1 phono
Outputs	3 HDMI
Supported Audio Formats	MP3, WAV, FLAC, ALAC, DSD
Total Harmonic Distortion	0.05% (20 Hz - 20 kHz)
