Denon AVR-A1H User Manual

.
FDL FDR
BDL BDR
SDL SDR
FDL/FDR
(Front Dolby speaker
left/right):
Place the FRONT Dolby Atmos Enabled speaker
on the front speaker. For a Dolby Atmos Enabled
integrated with a front speaker, place the Dolby
Atmos Enabled speaker instead of the front
speaker.
SDL/SDR
(Surround Dolby
speaker left/right):
Place the SURROUND Dolby Atmos Enabled
speaker on the surround speaker. For a Dolby
Atmos Enabled speaker integrated with a surround
speaker, place the Dolby Atmos Enabled speaker
instead of the surround speaker.
BDL/BDR
(Back Dolby speaker
left/right):
Place the BACK Dolby Atmos Enabled speaker on
the surround back speaker. For a Dolby Atmos
Enabled speaker integrated with a surround back
speaker, place the Dolby Atmos Enabled speaker
instead of the surround back speaker.
About Dolby Atmos Enabled speakers
Dolby Atmos Enabled speakers reflect the sound off the ceiling to allow
the sound to come from over your head by using a special upward-
pointing speaker that is placed on the floor.
You can enjoy the Dolby Atmos 3D sound even in an environment where
speakers cannot be installed on the ceiling.
.
Contents
Connections Playback Settings Tips Appendix
36
Front panel Display Rear panel Remote Index

Denon AVR-A1H Specifications

General

Channels	15.4
Power Output	150 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
HDMI Inputs	7
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
Auro-3D	Yes
HEOS Built-in	Yes
Wi-Fi	Yes
Bluetooth	Yes
Weight	70.5 lbs
HDCP Support	HDCP 2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
Wireless Audio	AirPlay 2, Bluetooth, HEOS
Phono Input	Yes
Frequency Response	10 Hz - 100 kHz
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Inputs	7 HDMI, 1 phono
Outputs	3 HDMI
Supported Audio Formats	MP3, WAV, FLAC, ALAC, DSD
Total Harmonic Distortion	0.05% (20 Hz - 20 kHz)
