o
When 5.1-channel speakers are installed
.
z1
z2
FL
SW
C
SL
FR
SR
z1 22° - 30° z2 120°
o
Layout including height speakers and ceiling
speakers
n
Height speaker layout example
Combination of 5.1-channel layout and front height/rear height/center
height speakers.
.
FHL FHR
C
FL FR
SW
SL SR
RHL RHR
Contents
Connections Playback Settings Tips Appendix
39
Front panel Display Rear panel Remote Index

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-A1H and is the answer not in the manual?

Denon AVR-A1H Specifications

General IconGeneral
Channels15.4
Power Output150 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
HDMI Inputs7
HDMI Outputs3
Dolby AtmosYes
DTS:XYes
IMAX EnhancedYes
Auro-3DYes
HEOS Built-inYes
Wi-FiYes
BluetoothYes
Weight70.5 lbs
HDCP SupportHDCP 2.3
HDR CompatibilityHDR10, HDR10+, Dolby Vision, HLG
Wireless AudioAirPlay 2, Bluetooth, HEOS
Phono InputYes
Frequency Response10 Hz - 100 kHz
Voice ControlAmazon Alexa, Google Assistant, Apple Siri
Inputs7 HDMI, 1 phono
Outputs3 HDMI
Supported Audio FormatsMP3, WAV, FLAC, ALAC, DSD
Total Harmonic Distortion0.05% (20 Hz - 20 kHz)
