Refer to the example connection for “Example connection for the Auro-3D
9.1-channel system” (v p. 61) when playing Auro-3D with a 9.1-
channel system using the basic 5.1-channel system and the front height
and surround height speakers.
Also refer to the connection example for “Example connection for the
Auro-3D 13.1-channel system” (v p. 67) when playing Auro-3D with a
13.1-channel system by adding the Surround Back, Top Surround and
Center Height speakers.
0
In addition to the connections described in
p.48 - 80, this unit allows for various
speaker connections with the “Amp Assign” setting.
Also refer to the menu screen in “View Terminal Config.” on the “Amp Assign”
setting screen, which shows how to make connections in your environment.
.
CENTER SURROUND SURROUNDFRONTFRONT CENTER SURROUND SURR.BACK SURROUNDFRONT SURR. BACK FRONT HEIGHT1 HEIGHT1HEIGHT1 HEIGHT1
F.HEIGHT R.HEIGHTSURR.BACKSURROUNDCENTERFRONT
HEIGHT2
HEIGHT2
SUBWOOFER
12
SUBWOOFER
SPEAKERS
Speakers/Amp Assign
PRE OUT
Assign Mode 11.1ch + ZONE2
Back
ZONE2
HEIGHT4HEIGHT3 HEIGHT3 HEIGHT4
Contents
Connections Playback Settings Tips Appendix
47
Front panel Display Rear panel Remote Index

Denon AVR-A1H Specifications

General

Channels	15.4
Power Output	150 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
HDMI Inputs	7
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
Auro-3D	Yes
HEOS Built-in	Yes
Wi-Fi	Yes
Bluetooth	Yes
Weight	70.5 lbs
HDCP Support	HDCP 2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
Wireless Audio	AirPlay 2, Bluetooth, HEOS
Phono Input	Yes
Frequency Response	10 Hz - 100 kHz
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Inputs	7 HDMI, 1 phono
Outputs	3 HDMI
Supported Audio Formats	MP3, WAV, FLAC, ALAC, DSD
Total Harmonic Distortion	0.05% (20 Hz - 20 kHz)
