Denon AVR-S530BT Service Manual

1. Version Display Mode
1.1. Actions
Version information is displayed when the device is started in this mode.
1.2. Starting up
AVR-S530BT
· While holding down buttons "
TUNER PRESET CH+
" and "
TUNE -
" simultaneously, press the power
button to turn on the power.
AVR-X540BT
· While holding down buttons "
TUNE +
" and "
DIMMER
" simultaneously, press the power button to
turn on the power.
then press the "
STATUS
" button to display the information in section 1.3 on the display.
1.3. Display Order
Error information(See "1.4. Error display") →
q
Model destination information
→
w
Main µ-com →
e
Main IAP →
r
DSP version →
t
OSD version →
y
USB version
q
Model destination information :
AVR-S530 E3 *
AVR-X540 \\\ *
\
: Region (E3, E2, E1C)
w
Main µ-com :
Main :**.**
e
Main IAP :
Main IAP V**.**
r
DSP version :
DSP.*.*.*
t
OSD version :
OSD :**.**
y
USB version :
USB.**.**.**
1.4. Error display
See the table below for descriptions of the displayed errors and countermeasures for these.
If multiple errors occur, only one item is displayed.
Condition
States Display
DSP NG Cannot execute DSP reset in DSP code boot.
DSP ERROR 01
DSP OK - (No Error display)
67
Caution in
servicing
Electrical Mechanical Repair Information Updating
