Denon AVR-S530BT Service Manual

POWER
REF No. Part No. Part Name Remarks Q'ty New Ver
! CY602 943132100800S CAP, CERAMIC(X1/Y1, 470pF, AC400V) CCKDCT471KB 1 *
! F3003 943652500510D FUSE(932Series, 250V/1.25A) CBA2J1250TLEBT 1
! F3004 943652500510D FUSE(932Series, 250V/1.25A) CBA2J1250TLEBT 1
! F6001 963652010510S FUSE(S506 Series, 250V,2A) E3 CBA2C2000TLEC 1
! F6001 963652010500S FUSE(S506 Series, 250V,1.6A) E2,E1C CBA2C1600TLEC 1
F6001 nsp HOLDER , FUSE KJCFC5S 2
! F6002 0520100170060 FUSE(218Series, 250V/5A) E3 KBA2C5000TLEY 1
! F6002 00D9430199109 FUSE(218Series, 250V/2.5A) E2,E1C KBA2C2500TLEY 1
F6002 nsp HOLDER , FUSE KJCFC5S 2
L6001 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
! LF602 963111010230S LINE FILTER, 27mH E3 CLZ9Z126Z 1
! LF602 943111100410S LINE FILTER, 50mH E2,E1C CLZ9Z133Z 1
! RY601 963682010370S RELAY,HL31-1AT-5H,DC5V,1C1P CSL1C006ZE 1
T6001 943102100720S TRANS, SWITCHING VLT9Z132ZW 1
